Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| Desktop panel thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Seated knee clearance height | 670 mm | |
| Seated knee clearance width | 1100 mm | |
| Seated knee clearance depth | 600 mm | |
| Metal leg tube wall thickness | 1.5 mm | |
| X-leg frame footprint width | 700 mm | |
| Left storage pedestal dimensions | 450 x 600 x 700 mm | |
| CPU compartment internal dimensions | 250 x 500 x 450 mm | |
| Cable grommet diameter | 60 mm | |
| Pedestal drawer internal depth | 400 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for pedestal doors | 80000 cycles | |
| Unpackaged product weight | 60 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Recommended maximum user weight | 120 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop surface | Dark wood-grain thermally fused melamine laminate | |
|---|---|---|
| Desktop core | E1-grade engineered particle board | |
| Desktop edge trim | 2 mm thick impact-resistant ABS edging | |
| Support legs | Dual-tone powder-coated steel X-frame | |
| Pedestal carcass | 18 mm thick grey melamine-faced engineered wood | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Lock mechanism | Zinc alloy keyed cam lock | |
| Leveling feet | Reinforced nylon adjustable floor glides | |
| CPU compartment shelf | 15 mm thick melamine panel with ventilation slots | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Fixed-height work surface | 750 mm standard office work height, no electric or manual height adjustment | |
|---|---|---|
| Pedestal storage layout | Top locking utility drawer, lower open CPU compartment, no swinging cabinet door | |
| Cable management | 60 mm rear desktop cable grommet with under-desk cable routing space | |
| X-frame bracing stability | Crossed angled steel legs provide lateral rigidity to reduce work surface wobble | |
| Floor leveling adjustment | 10 mm vertical adjustment range on foot glides to align desk on uneven flooring | |
| Locking drawer security | Keyed lock secures top drawer to protect confidential documents and valuables | |
| CPU storage access | Open front-facing CPU compartment allows easy access to computer ports and power buttons | |
| Under-desk modesty panel | Full-height grey panel between knee well and pedestal for seated privacy | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for manager/CEO offices with dark grey contemporary interior finishes, paired with ergonomic task chairs | |
|---|---|---|
| Home office premium workspace | Ideal for dedicated home executive offices requiring integrated storage and CPU placement for desktop setups | |
| Corporate management suite | Fits commercial office tower management floors with floor-to-ceiling windows and premium millwork surroundings | |
| Single-user seated workstation | Configured for one user performing daily computer-based office work, document review, and meetings from the desk | |
| Recommended seating pairing | Mid-back mesh ergonomic office chairs with five-star caster bases to match the desk height and style | |
| Peripheral integration | Supports dual monitor setups, desk mats, small office plants and desktop organizers on the work surface |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial office desk design | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables, mechanical safety and dimensional requirements for fixed-height desks | |
| EN 13722:2004 | Office furniture storage units, safety and strength requirements for the integrated pedestal |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Desk Products standard, applicable to structural load and durability performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard, applicable to drawer and pedestal performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural performance and finish of the desk | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of formaldehyde for wooden furniture, applicable to E1-grade panel materials | |
| GB/T 10357.1-1989 | Furniture test for surface mechanical properties of tables, applicable to desktop load and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural performance and finish of the desk; 2. GB 18584-2001: Indoor decoration material limit of formaldehyde for wooden furniture, applicable to E1-grade panel materials; 3. GB/T 10357.1-1989: Furniture test for surface mechanical properties of tables, applicable to desktop load and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
