Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1500 x 1200 x 750 mm | |
|---|---|---|
| Per-user work surface width | 750 mm | |
| Work surface depth per seat | 600 mm | |
| Central privacy divider height | 350 mm | |
| Knee clearance height under desk | 650 mm | |
| Knee clearance width per seat | 700 mm | |
| Tabletop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Side storage pedestal dimensions | 400 x 600 x 680 mm | |
| CPU storage compartment width | 250 mm per bay | |
| Steel leg wall thickness | 1.5 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Pedestal door hinge cycle rating | 80000 cycles | |
| Recommended user count | 2 | |
| Product net weight | 75 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | Melamine-faced MFC board, light oak finish, 2mm PVC edge banding | |
|---|---|---|
| Support legs | Powder-coated off-white steel, splayed angled design | |
| Central privacy divider | Grey fabric-wrapped fiberboard core, low profile | |
| Storage pedestal frame | Powder-coated steel frame, off-white finish, lockable drawer | |
| Drawer hardware | Cold-rolled steel slide rails, keyed cam lock | |
| Adjustable feet | Nylon-base leveling glides at leg and pedestal base | |
| Cable management components | ABS plastic grommets and under-desk cable tray | |
| Fasteners and hardware | Zinc-plated steel connection hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Privacy screening | Central fabric divider blocks direct line of sight between opposite seated users | |
|---|---|---|
| Secure storage | Integrated right-side lockable drawer secures personal documents and office supplies | |
| CPU storage | Two open under-desk bays hold upright full-size desktop computer towers | |
| Cable management | Top-surface grommets route power and data cables to under-desk tray for organized wiring | |
| Level adjustment | Underside leveling feet adjust by 10mm to stabilize desk on uneven floors | |
| Work surface access | 360-degree perimeter access allows seated entry from two opposite sides | |
| Modular compatibility | Desk connects to matching workstation units for open-plan bench expansions | |
| Anti-wear protection | Edge banding prevents chipping at impact points along worktop perimeter | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Provides efficient two-person seating with visual privacy for daily task work | |
|---|---|---|
| Small team workspaces | Compact footprint supports collaborative two-person teams without excess floor space use | |
| Startup office fit-outs | Integrated storage and CPU bays reduce need for separate furniture purchases | |
| Home office dual-work setup | Neutral light wood and off-white finish suits residential work spaces for two users | |
| Hot-desking zones | Durable commercial-grade surfaces withstand frequent shared use across shift changes | |
| Administrative work areas | Secure lockable storage supports document storage for admin and clerical staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Safety and strength requirements for office work desks | |
|---|---|---|
| EN 527-2:2016 | Dimensional and functional requirements for office desks | |
| EN 13722:2004 | Strength and durability requirements for office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3327-2016 | Quality requirements for metal office furniture | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3327-2016: Quality requirements for metal office furniture; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
