Product supplierL-Shaped Reception Desk with Integrated Hutch and Privacy Panels, 25 mm melamine-faced wood-composite board with walnut grain finish and sealed exposed edges
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 165 kg | |
|---|---|---|
| Worktop distributed load | 80 kg per work position | |
| Hutch shelf load | 20 kg per compartment | |
| Drawer static load | 15 kg | |
| Seating capacity | 2 reception staff | |
| Visitor queue capacity at counter | 2 to 3 visitors | |
| Panel fastener pull-out acceptance value | 450 N per connector | |
| Adjustable foot leveling range | 10 mm | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop | 25 mm melamine-faced wood-composite board with walnut grain finish and sealed exposed edges | |
|---|---|---|
| Privacy and exterior panels | 18 mm matte grey melamine-faced composite panels with square edge banding | |
| Storage cabinet doors and drawer fronts | Walnut-look melamine panel with black recessed pulls and matching edge banding | |
| Structural support | 50 mm black powder-coated steel cylindrical leg with floor contact foot | |
| Internal hardware | Steel cam-lock connectors, hinges, drawer slides, shelf supports, and wall-tie brackets | |
| Desk dividers | Rigid light grey privacy panels with smooth facing and low-profile edge trim |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Two-station reception layout | Two seated work positions share one continuous L-shaped counter separated by low desktop screens | |
|---|---|---|
| Visitor privacy screening | 1100 mm front and side panels block direct sightlines into staff screens, keyboards, and under-desk space | |
| Integrated storage organization | Rear hutch open cubbies, one drawer, and one lower cabinet provide separate storage for documents, devices, and personal items | |
| Equipment and cable layout | Hutch shelf zone supports a printer or CPU, with rear cable routing recommended at 80 mm grommet openings |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total gross weight | 185 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office entrance | Suitable for a main lobby where two staff can greet visitors while keeping screens and paperwork screened behind the high front panel | |
|---|---|---|
| Hotel, clinic, or service center reception | Provides visitor-facing counter space plus hutch storage for printers, documents, registers, and daily reception supplies |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1 office desk safety and dimensions | Relevant to work-surface height, strength, and safety requirements for the seated staff work area | |
|---|---|---|
| EN 15372 office storage strength | Applicable to the hutch shelves, cabinet, drawer, and load-bearing storage compartments | |
| EN 13986 wood-based panels | Panel performance reference for composite boards used in worktops, modesty panels, and cabinet construction |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324 dimensional and structural suitability | General technical standard for wooden furniture cabinets and panel furniture used as a dimensional and workmanship acceptance reference | |
|---|---|---|
| GB/T 3325 metal furniture suitability | Applicable to the steel support leg and load-bearing metal hardware if metal components are supplied | |
| GB 18580 emission control | Formaldehyde emission control for wood-based panels and finishing materials used in the reception desk body | |
| GB/T 10357 furniture strength testing | Desk and cabinet strength, stability, and durability test reference for the worktop, storage modules, and support leg |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324 dimensional and structural suitability: General technical standard for wooden furniture cabinets and panel furniture used as a dimensional and workmanship acceptance reference; 2. GB/T 3325 metal furniture suitability: Applicable to the steel support leg and load-bearing metal hardware if metal components are supplied; 3. GB 18580 emission control: Formaldehyde emission control for wood-based panels and finishing materials used in the reception desk body; 4. GB/T 10357 furniture strength testing: Desk and cabinet strength, stability, and durability test reference for the worktop, storage modules, and support leg; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
