Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 1400 x 755 mm | |
|---|---|---|
| Single user desktop size | 1400 x 700 mm | |
| Desktop thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Desktop privacy divider height above surface | 570 mm | |
| Knee clearance height under desktop | 690 mm | |
| Drawer internal dimensions | 400 x 500 x 150 mm | |
| Central storage pedestal width | 800 mm | |
| Cable grommet diameter | 80 mm | |
| Steel leg tube outer diameter | 50 mm | |
| Floor clearance under central pedestal | 50 mm | |
| Steel leg wall thickness | 2.0 mm | |
| Privacy divider panel thickness | 32 mm | |
| Under-desk cable tray depth | 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Single desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 operations | |
| Hinge cycle rating for cabinet doors | 80000 operations | |
| Unit net weight | 120 kg | |
| Recommended maximum user weight per seat | 136 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Commercial product warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surfaces | E1 grade melamine laminated MFC board, scratch-resistant matte finish | |
|---|---|---|
| Angled support legs | Powder-coated dark matte steel tubing, splayed tapered design | |
| Desktop privacy dividers | Rigid fabric-wrapped fibreboard with curved top edge, light grey supports | |
| Central storage cabinet panels | Matching melamine laminated MFC, two-tone light grey and dark grey finish | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Cabinet handles | Recessed silver-toned metal pull handles, lockable upper drawer fronts | |
| Cable management components | ABS plastic grommets, under-desk steel cable tray | |
| Pedestal support feet | Small powder-coated steel adjustable leveller feet | |
| Edge banding | 2mm thick impact-resistant PVC edging, color-matched to desktop finish | |
| Hardware fasteners | Zinc-plated steel cam locks, screws and connecting bolts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Two separate equal-size work surfaces for two seated users, separated by central storage | |
|---|---|---|
| Central shared lockable storage | Two upper keyed-alike lockable drawers, two lower hinged cabinet doors for shared document storage | |
| Desktop cable management | Recessed cable grommets on each work surface route power and data cables to under-desk tray | |
| Splayed leg stability design | Four outer angled steel legs distribute weight to prevent wobble during typing and desk use | |
| Desktop privacy separation | Curved-top divider screens block direct line of sight between adjacent seated users | |
| Adjustable levelling feet | Threaded feet on legs and central pedestal compensate for uneven floor surfaces | |
| Knock-down modular assembly | Flat-pack CKD design allows reconfiguration of workstation clusters for open plan offices | |
| Full extension drawer access | Ball-bearing slides allow full drawer pull-out for complete access to stored documents | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Designed for clustered staff seating in open office layouts, dividing individual work zones | |
|---|---|---|
| Small business start-up offices | Provides two dedicated work positions with integrated storage in a compact footprint | |
| Shared co-working spaces | Modular design allows flexible arrangement for shared hot-desking work areas | |
| Corporate department work zones | Suitable for admin, customer service or data entry teams requiring separated work surfaces | |
| Hybrid office environments | Integrated cable management supports monitor, laptop and office device connectivity | |
| Government and institutional offices | Durable commercial construction meets heavy daily use requirements for public sector workspaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worktop and frame performance | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office worktables dimensional safety and strength test methods | |
| EN 13722:2004 | Office furniture storage units strength and durability requirements | |
| EN 13986:2004+A1:2015 | Wood-based panels formaldehyde emission limits for indoor furniture use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for office pedestal and cabinet components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and storage construction | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture, applicable to steel leg and frame strength testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF panel materials | |
| GB/T 4897.3-2015 | Requirements for particleboard used in furniture, applicable to worktop and cabinet core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and storage construction; 2. GB/T 3325-2017: Test methods for metal furniture, applicable to steel leg and frame strength testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MFC/MDF panel materials; 4. GB/T 4897.3-2015: Requirements for particleboard used in furniture, applicable to worktop and cabinet core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
