Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 1100 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 200 kg | |
|---|---|---|
| Product net weight | 85 kg | |
| Recommended user capacity | 2 users | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Leveling foot maximum load per foot | 40 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | 25mm melamine-faced particleboard, 2mm PVC edge banding | |
|---|---|---|
| Central support cabinet panels | 18mm melamine-faced particleboard, light gray matte finish | |
| Right pedestal drawer/cabinet fronts | 18mm melamine-faced particleboard, matching oak wood grain finish | |
| Desktop divider panel | 18mm MDF core, light off-white fabric wrap | |
| Divider mounting hardware | Orange powder-coated steel brackets | |
| Drawer handles | Orange ABS plastic integrated pulls | |
| Cabinet frame hardware | Zinc-plated steel connector fittings, knockdown assembly | |
| Leveling feet | Nylon base with steel threaded stem | |
| Cable grommet trim | ABS plastic cutout edge under divider | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management pass-through | Central open slot under divider routes power/data cables between two work zones | |
|---|---|---|
| Upper stationery drawer | Full-extension 3-section slide for small office supply storage | |
| Lower filing cabinet | Swing door compartment sized for A4 suspension file storage | |
| Desk divider privacy screen | Fixed-mounted panel blocks direct line of sight between opposite seated users | |
| Central open storage shelf | Fixed open compartment for CPU tower or shared office supply storage | |
| Leveling foot adjustment | Threaded stem adjusts 10mm to stabilize desk on uneven flooring | |
| Knockdown assembly | Cam-lock fitting construction for on-site assembly and reconfiguration | |
| Pedestal structural support | Integrated right storage pedestal and central cabinet eliminate need for separate leg supports | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office work zones | Suitable for two-person team seating in general open office layouts | |
|---|---|---|
| Small startup office spaces | Ideal for compact offices requiring integrated storage without extra furniture | |
| Call center seating areas | Suitable for high-density call center workstation rows with visual privacy divider | |
| Branch office general workstations | Applicable for regional office standard staff seating configurations | |
| Temporary project team spaces | Suitable for short-term project team setups due to knockdown reconfigurable design | |
| Educational staff work areas | Applicable for school or training institution administrative staff seating |
EU Market Access Requirements* EN Standards
| Office desk strength and durability | EN 527:2002+A1:2019 | |
|---|---|---|
| Office desk surface finish durability | EN 12721:2000 | |
| Office furniture stability requirement | EN 14073:2004 |
US and Canada office-furniture standards
| Office desk load and durability | ANSI/BIFMA X2021 | |
|---|---|---|
| Storage unit performance | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Desk surface dimensional tolerance | GB/T 3324 | |
|---|---|---|
| Desk edge safety requirement | GB 28007 | |
| Formaldehyde emission limit | GB 18580 |
This product must meet the following technical requirements: 1. Desk surface dimensional tolerance: GB/T 3324; 2. Desk edge safety requirement: GB 28007; 3. Formaldehyde emission limit: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
