Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 135 kg | |
| Recommended user count | 2 people | |
| Divider sound transmission class | 15 STC | |
| Leveling foot adjustment range | 15 mm | |
| Drawer cycle durability | 50000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop | 25mm MDF core with wood-grain high-pressure laminate, anti-scratch finish | |
|---|---|---|
| Table frame | 1.5mm thick powder-coated white steel, angled front leg, square inner support | |
| Privacy dividers | 18mm MDF core wrapped in teal woven polyester fabric, beveled edges | |
| Pedestal carcass | 18mm melamine-faced particle board, two-tone taupe and wood-grain finish | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides, zinc-plated finish | |
| Locks | Zinc alloy cam locks with matching keys, one per lockable drawer | |
| Leveling feet | Nylon base with steel threaded insert, adjustable height | |
| Pen tray accessory | ABS plastic clip-on storage organizer attached to divider end | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Worksurface layout | Two equal 1200mm wide work positions arranged face-to-face, shared central support structure | |
|---|---|---|
| Privacy screening | Central fabric dividers block direct line of sight between seated users, reduce cross-talk | |
| Integrated storage | Four lockable drawers total (two per user) at each work position corner for file storage | |
| Cable management | Open gap between central pedestals allows cable routing from floor to worktop for power/data | |
| Floor leveling | Adjustable feet at each pedestal base stabilize the desk on uneven hard flooring | |
| Drawer operation | Full-extension drawers open fully to provide complete access to stored documents and supplies | |
| Locking security | Keyed cam locks secure upper drawers to protect personal or confidential office items | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan offices | Dense 2-person workstations maximize space efficiency while maintaining user privacy | |
|---|---|---|
| Small business workspaces | Integrated storage eliminates need for separate filing cabinets for small teams | |
| Call center environments | Divided work positions reduce cross-talk and distraction between adjacent staff | |
| Co-working facilities | Standard dimensions and lockable storage suit flexible shared work area deployments | |
| Administrative work areas | Spacious worktops support computer, paperwork and reference materials for office staff | |
| Government office fit-outs | Durable laminate construction meets high-traffic long-term use requirements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for European market procurement | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical performance requirements for workstations | |
| EN 1335-1:2020 | Office furniture ergonomic reference for desk clearance dimensions to match seating |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate worktop and cabinet components | |
|---|---|---|
| GB/T 3327-2018 | Office desk performance requirements, applicable to structural load and stability testing | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit, applicable to wood-based panel components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to strength and durability validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate worktop and cabinet components; 2. GB/T 3327-2018: Office desk performance requirements, applicable to structural load and stability testing; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit, applicable to wood-based panel components; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to strength and durability validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
