Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2000 x 1600 x 745 mm | |
|---|---|---|
| Work surface thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Privacy divider height above work surface | 400 mm | |
| Under-desk knee clearance height | 620 mm | |
| Per-user ergonomic work zone depth | 700 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Central CPU compartment dimensions | 250 x 500 x 500 mm | |
| Cable grommet diameter | 80 mm | |
| Steel leg tube wall thickness | 1.5 mm | |
| Divider panel thickness | 25 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static load per work surface | 90 kg | |
|---|---|---|
| Mobile pedestal drawer static load | 30 kg per drawer | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended maximum user weight per seat | 136 kg | |
| Net weight of complete workstation set | 125 kg | |
| Cable tray load capacity | 5 kg | |
| Commercial warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | E1-grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Support legs | 1.5mm wall thickness powder-coated steel, splayed tapered design | |
| Privacy dividers | Particleboard core with matte dark grey laminate finish, standoff-mounted | |
| Mobile pedestal cabinet bodies | Matching melamine-faced particleboard with steel drawer runners | |
| Casters for mobile pedestals | 50mm diameter black nylon lockable swivel casters, 2 per unit with brake | |
| Central CPU compartment | Melamine-faced particleboard enclosure with integrated cable access port | |
| Hardware and fasteners | Zinc-plated steel assembly hardware with corrosion-resistant coating | |
| Cable management components | ABS plastic cable grommets and under-desk raceway | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Privacy division | Three standoff-mounted low dividers separate two adjacent work zones to reduce visual distraction | |
|---|---|---|
| Mobile storage | Two lockable 3-drawer rolling pedestals fit fully under the work surface for personal file and supply storage | |
| CPU support | Central under-desk compartment secures desktop computer towers with cable access to work surface | |
| Cable management | Integrated grommets and under-desk raceway route power and data cables away from leg clearance zones | |
| Floor leveling | Adjustable glide feet on leg bases compensate for uneven office flooring | |
| Knock-down assembly | Flat-packed design allows on-site assembly with standard included hex key hardware | |
| Modular expansion | Desk units can be connected side-by-side to create larger open-office bench clusters | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Creates two dedicated work positions in co-working and corporate offices without full cubicle walls | |
|---|---|---|
| Small startup team work areas | Provides personal storage and privacy for two staff in compact office footprints | |
| Home office dual-user setups | Serves shared workspaces for partners or remote working households with separate storage | |
| Flexible hot-desking zones | Modular design supports reconfigurable open office layouts as team sizes change | |
| Administrative and clerical work areas | Supports computer-based office tasks with dedicated CPU space and cable management |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to desk structure performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical safety requirements | |
| EN 1335-2:2009 | Office furniture seating safety reference for compatible user weight ratings |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and durability standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for included mobile pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk top and cabinet components | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture strength and durability, applicable to steel frame and legs | |
| GB 18584-2001 | Limits of formaldehyde emission for wooden furniture, applicable to E1-grade panel components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk top and cabinet components; 2. GB/T 3325-2017: Test methods for metal furniture strength and durability, applicable to steel frame and legs; 3. GB 18584-2001: Limits of formaldehyde emission for wooden furniture, applicable to E1-grade panel components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
