Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 1200 x 750 mm | |
|---|---|---|
| Per-seat worksurface width | 1200 mm | |
| Per-side worksurface depth | 600 mm | |
| Under-desk knee clearance height | 650 mm | |
| Knee clearance depth per seat | 450 mm | |
| Central privacy divider height above desk | 350 mm | |
| Privacy divider thickness | 32 mm | |
| Worktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Support leg wall thickness | 1.5 mm | |
| Support beam section | 50 x 25 mm | |
| Per-pedestal dimensions | 400 x 600 x 600 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer internal depth | 500 mm | |
| Five-star base diameter (paired chair) | 640 mm | |
| Finished Top Thickness | 50 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 120 kg | |
|---|---|---|
| Drawer slide cycle life | 50000 cycles | |
| Total workstation net weight | 280 kg | |
| Maximum user weight per seat | 120 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Available color options | 12 | |
| Product warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop | 25 mm E1-grade melamine-faced particleboard | |
|---|---|---|
| Edge banding | 2 mm thick PVC edge trim | |
| Support frame and legs | 1.5 mm thick cold-rolled steel with matte powder coat | |
| Central privacy dividers | Fabric-laminated medium-density fiberboard | |
| Drawer pedestals | Melamine-faced particleboard cabinet with steel drawer fronts | |
| Drawer slides | Cold-rolled steel ball-bearing telescopic slides | |
| Cable management components | ABS plastic grommets and under-desk steel cable raceway | |
| Leveling feet | Reinforced nylon with adjustable steel thread | |
| Hardware fasteners | Zinc-plated steel bolts and cam locks | |
| Pedestal drawer locks | Keyed-alike zinc alloy cylinder locks | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating layout | Face-to-face 2-row arrangement for 6 individual work positions | |
|---|---|---|
| Cable management | Integrated grommets in dividers connect to under-desk raceways | |
| Drawer storage | Two lockable drawers per workstation pedestal | |
| Privacy screening | Low central divider provides visual separation between opposite seats | |
| Leveling adjustment | 15 mm vertical adjustment on all leg feet | |
| Modular assembly | Knocked-down modular components connect via steel beam joints | |
| Knee space access | Clear unobstructed seated entry at each position | |
| Surface utility | Scratch and stain-resistant melamine finish | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office team zones | Ideal for 6-person teams in tech, admin or call center environments | |
|---|---|---|
| Startup co-working spaces | Modular design supports flexible team seating arrangements | |
| Corporate staff work areas | Neutral finish palette matches modern commercial office interior design | |
| Small business office layouts | Integrated storage eliminates need for separate filing cabinets | |
| Training department work areas | Fixed pedestal storage keeps supplies organized at each seat | |
| Branch office open work zones | Standardized dimensions simplify bulk procurement and layout planning |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety requirements | |
| EN 13722:2004 | Furniture storage units strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2015 | Particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3325-2017: Metal furniture general technical requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 4897.3-2015: Particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
