L-Shaped Executive Office Desk with Integrated Storage, Power Dock and Privacy Divider (model EXEC-L2800-WAL-ACRYLDIV) is listed under Open Workstation. Dimensions: 2800 × 1000 × 750 mm. Materials: E1-grade engineered wood with walnut wood grain melamine finish, water-resistant coating. Load capacity: 136 kg. Product Features: modern,commercial,styling,integrated,power,system,lockable,storage,fixed-height,workstation. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | Fanshidun | Model | EXEC-L2800-WAL-ACRYLDIV |
| Overall dimensions (W × D × H) | 2800 × 1000 × 750 mm | desktop thickness | 30 mm |
| edge band thickness | 2 mm | Y-shaped steel leg wall thickness | 2 mm |
| seated knee clearance height | 650 mm | knee clearance width | 1200 mm |
| return storage cabinet dimensions | 1400 x 600 x 650 mm | desktop cable grommet diameter | 80 mm |
| curved acrylic privacy divider dimensions | 800 x 300 x 8 mm | attached plant shelf diameter | 150 mm |
| storage drawer internal height | 280 mm | Finished Top Thickness | 50 mm |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | Leg / Support Section | 80 mm main section with 2 mm metal wall |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm | desktop static load capacity | 136 kg |
| drawer slide cycle rating | 50000 cycles | cabinet hinge cycle rating | 80000 cycles |
| product net weight | 82 kg | recommended user weight capacity | 150 kg |
| Qi wireless charging output | 15 W | Top Static Load Reference | 150 kg uniformly distributed |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | Hinge Opening Life | Acceptance target 80000 cycles |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | work surface | E1-grade engineered wood with walnut wood grain melamine finish, water-resistant coating |
| support leg | Black powder-coated carbon steel, Y-shaped cantilever design with brushed chrome accent trim | privacy divider | 8mm tinted translucent acrylic with purple edge glow, curved top profile, mounted to central power rail |
| return storage cabinet frame | Black matte engineered wood cabinet body with walnut wood grain front panel and brushed steel lock plate | storage hardware | Zinc-alloy keyed cam lock, steel full-extension ball-bearing drawer slides |
| power rail housing | Matte black ABS plastic with integrated AC sockets, USB-A/USB-C ports and Qi wireless charging pad | plant shelf bracket | Black powder-coated steel post with smoked tempered glass top surface |
| cabinet leveling feet | Nylon height-adjustable glides, 10mm adjustment range | surface edge treatment | 2mm thick PVC edge banding, rounded safety profile |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | Edge Band Thickness | 2 mm |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | integrated power system | Center-mounted power rail includes 2 universal AC outlets, 2 USB-A ports, 1 USB-C port and flush Qi wireless charging pad for device power |
| lockable return storage | Right-side return cabinet has two lockable drawers sized for legal/letter hanging files and one enclosed storage compartment, keyed alike for single-key access | cable management | Recessed under-desk steel cable tray routes power and data cables from the central rail to floor outlets, eliminating surface clutter |
| desktop privacy divider | Curved purple-tinted acrylic divider mounts to the central power rail, creating visual screen separation between the user and opposite desk side | cantilever leg support | Y-shaped left-side steel leg provides open unobstructed knee space without cross-braces that block seated leg movement |
| leveling adjustment | Nylon glides on cabinet base and leg feet adjust 10mm to compensate for uneven office flooring, stabilizing the work surface | attached accessory shelf | Raised circular shelf mounted to the power rail holds small potted plants or personal items without occupying primary work surface |
| surface maintenance | Water and stain resistant melamine finish wipes clean with standard office cleaning products, resisting everyday coffee and paper abrasion | Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | Reference Packaging Volume | 1 m³/set |
| corporate executive office | Suitable for CEO, director and senior management private offices with professional walnut and black finish | open-plan management workstation | Configurable for open office management positions with integrated privacy divider and power access |
| home office premium workspace | Works for dedicated high-end home office use requiring file storage and built-in device charging | small private meeting workspace | Large work surface supports informal 2person side meetings in addition to solo desk work |
| IT and creative professional use | Integrated power dock and cable management support multiple monitors, laptops and mobile devices | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2800 × 1000 × 750 mm | |
|---|---|---|
| desktop thickness | 30 mm | |
| edge band thickness | 2 mm | |
| Y-shaped steel leg wall thickness | 2 mm | |
| seated knee clearance height | 650 mm | |
| knee clearance width | 1200 mm | |
| return storage cabinet dimensions | 1400 x 600 x 650 mm | |
| desktop cable grommet diameter | 80 mm | |
| curved acrylic privacy divider dimensions | 800 x 300 x 8 mm | |
| attached plant shelf diameter | 150 mm | |
| storage drawer internal height | 280 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static load capacity | 136 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| product net weight | 82 kg | |
| recommended user weight capacity | 150 kg | |
| Qi wireless charging output | 15 W | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| work surface | E1-grade engineered wood with walnut wood grain melamine finish, water-resistant coating | |
|---|---|---|
| support leg | Black powder-coated carbon steel, Y-shaped cantilever design with brushed chrome accent trim | |
| privacy divider | 8mm tinted translucent acrylic with purple edge glow, curved top profile, mounted to central power rail | |
| return storage cabinet frame | Black matte engineered wood cabinet body with walnut wood grain front panel and brushed steel lock plate | |
| storage hardware | Zinc-alloy keyed cam lock, steel full-extension ball-bearing drawer slides | |
| power rail housing | Matte black ABS plastic with integrated AC sockets, USB-A/USB-C ports and Qi wireless charging pad | |
| plant shelf bracket | Black powder-coated steel post with smoked tempered glass top surface | |
| cabinet leveling feet | Nylon height-adjustable glides, 10mm adjustment range | |
| surface edge treatment | 2mm thick PVC edge banding, rounded safety profile | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| integrated power system | Center-mounted power rail includes 2 universal AC outlets, 2 USB-A ports, 1 USB-C port and flush Qi wireless charging pad for device power | |
|---|---|---|
| lockable return storage | Right-side return cabinet has two lockable drawers sized for legal/letter hanging files and one enclosed storage compartment, keyed alike for single-key access | |
| cable management | Recessed under-desk steel cable tray routes power and data cables from the central rail to floor outlets, eliminating surface clutter | |
| desktop privacy divider | Curved purple-tinted acrylic divider mounts to the central power rail, creating visual screen separation between the user and opposite desk side | |
| cantilever leg support | Y-shaped left-side steel leg provides open unobstructed knee space without cross-braces that block seated leg movement | |
| leveling adjustment | Nylon glides on cabinet base and leg feet adjust 10mm to compensate for uneven office flooring, stabilizing the work surface | |
| attached accessory shelf | Raised circular shelf mounted to the power rail holds small potted plants or personal items without occupying primary work surface | |
| surface maintenance | Water and stain resistant melamine finish wipes clean with standard office cleaning products, resisting everyday coffee and paper abrasion | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| corporate executive office | Suitable for CEO, director and senior management private offices with professional walnut and black finish | |
|---|---|---|
| open-plan management workstation | Configurable for open office management positions with integrated privacy divider and power access | |
| home office premium workspace | Works for dedicated high-end home office use requiring file storage and built-in device charging | |
| small private meeting workspace | Large work surface supports informal 2person side meetings in addition to solo desk work | |
| IT and creative professional use | Integrated power dock and cable management support multiple monitors, laptops and mobile devices |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables – Safety and strength requirements for fixed-height commercial desks | |
|---|---|---|
| EN 527-2:2016 | Office work tables – Mechanical safety test methods for structural stability | |
| EN 13722:2004 | Performance requirements for office storage furniture integrated into desk returns |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products, covering static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for storage units integrated into office desk systems |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to wood worktop and cabinet components | |
|---|---|---|
| GB/T 3327-2018 | Performance test methods for office desks, applicable to static load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to wood worktop and cabinet components; 2. GB/T 3327-2018: Performance test methods for office desks, applicable to static load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
