| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1400 x 1200 x 1400 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Main work surface size | 1200 x 600 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1100 mm | |
| Cable grommet diameter | 60 mm | |
| Side hutch width | 400 mm | |
| Side hutch depth | 350 mm | |
| Upper open cubby size | 350 x 350 x 300 mm | |
| Lower cabinet door size | 350 x 700 mm | |
| Steel leg cross-section | 30 x 30 mm | |
| Edge band thickness | 2 mm | |
| Modesty panel height | 350 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Desktop static load capacity | 50 kg | |
|---|---|---|
| Recommended user weight capacity | 120 kg | |
| Drawer/hinge cycle rating | 80000 cycles | |
| Net product weight | 55 kg | |
| Coating surface hardness | 5H | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade engineered wood with light oak melamine laminate | |
|---|---|---|
| Storage hutch panels | E1 grade engineered wood with dark charcoal melamine laminate | |
| Cabinet door panel | E1 grade engineered wood with light oak melamine laminate | |
| Support legs | Powder-coated dark gray steel square tube | |
| Edge banding | 2 mm thick PVC matching panel finishes | |
| Hinges | Cold-rolled steel soft-close cabinet hinges | |
| Door handle | Matte black aluminum alloy pull handle | |
| Cable grommet | ABS plastic with black finish | |
| Internal shelves | 18 mm thick engineered wood with matching laminate | |
| Modesty panel | 18 mm thick engineered wood with dark charcoal melamine | |
| Adjustable foot pads | Nylon with steel threaded stems | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Embedded 60mm grommet routes monitor and power cables through work surface | |
|---|---|---|
| Open storage | Four upper open cubbies and two lower open shelves for frequently accessed items | |
| Enclosed storage | Single hinged lower cabinet conceals stored items and reduces visual clutter | |
| Level adjustment | Threaded nylon foot pads at base adjust for uneven floor surfaces | |
| Work surface layout | L-shaped configuration provides extended work area without full executive desk footprint | |
| Legroom access | Open under-desk bay accommodates standard rolling office chairs with full knee clearance | |
| Surface resistance | Melamine finish resists common office stains, scratches and minor water exposure | |
| Assembly design | Knock-down construction uses cam-lock fasteners for on-site assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff workstations | Compact L-shape fits standard workstation grid layouts for individual staff | |
|---|---|---|
| Home office study spaces | Integrated storage reduces need for separate bookshelves in small rooms | |
| Small business administrative areas | Suitable for reception, admin or clerical staff handling paperwork and computers | |
| Startup co-working spaces | Durable construction and simple styling fit flexible shared office environments | |
| School faculty office rooms | Provides work surface and storage for teachers preparing materials | |
| Individual cubicle replacement | Integrated hutch adds storage without separate partition panels |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable safety and strength requirements for office work desks | |
|---|---|---|
| EN 527-2:2019 | Applicable dimensional and ergonomic requirements for office work surfaces | |
| EN 15372:2016 | Applicable safety, strength and durability requirements for office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable performance standard for desk products used in office environments | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable performance standard for office storage units attached to desks |
Standards applicable to China-market projects
| GB/T 3325-2017 | Applicable general technical requirements for metal furniture frames and supports | |
|---|---|---|
| GB/T 3324-2017 | Applicable general technical requirements for wooden furniture panels and surfaces | |
| GB 18580-2017 | Applicable formaldehyde emission limit requirement for engineered wood panels | |
| GB/T 4893.8-2013 | Applicable surface wear resistance test for furniture laminate finishes |
This product must meet the following technical requirements: 1. GB/T 3325-2017: Applicable general technical requirements for metal furniture frames and supports; 2. GB/T 3324-2017: Applicable general technical requirements for wooden furniture panels and surfaces; 3. GB 18580-2017: Applicable formaldehyde emission limit requirement for engineered wood panels; 4. GB/T 4893.8-2013: Applicable surface wear resistance test for furniture laminate finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
