Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 1120 mm | |
|---|---|---|
| Worksurface height | 750 mm | |
| Per-user worksurface width | 1200 mm | |
| Per-user worksurface depth | 600 mm | |
| Knee clearance height | 650 mm | |
| Central storage unit width | 400 mm | |
| Privacy screen height above worksurface | 370 mm | |
| Drawer internal dimensions | 360 x 480 x 120 mm | |
| Cable grommet opening diameter | 80 mm | |
| Support leg diameter | 50 mm | |
| Desktop panel thickness | 25 mm | |
| Modesty panel height under worksurface | 400 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static worksurface load capacity | 150 kg per work position | |
|---|---|---|
| Recommended user count | 2 seated office workers | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Net workstation weight | 100 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Leveling foot adjustment range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface panels | E1 grade melamine-faced particleboard, 25mm thick, scratch-resistant matte finish | |
|---|---|---|
| Edge banding | 2mm thick PVC edging on all exposed panel edges | |
| Support legs | 50mm diameter cold-rolled steel, matte dark grey powder coating, decorative brass trim rings | |
| Privacy dividers | Fabric-upholstered MDF core, light beige finish, clip-on mounting brackets | |
| Central storage carcase | 18mm thick melamine-faced particleboard, dark grey matte finish | |
| Drawer fronts | 16mm thick melamine-faced particleboard, light off-white finish, black recessed plastic pulls | |
| Cable grommets | Black ABS plastic, recessed brush-style opening | |
| Leveling feet | Nylon base with steel threaded stem, black finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central upper open cubbies | 4 divided open storage compartments above drawer unit for quick-access office supplies | |
|---|---|---|
| Central drawer storage | Two pull-out lockable drawers positioned for shared access between two users | |
| Central lower open shelving | 2 divided open lower shelves for CPU towers, files or personal items | |
| Cable management system | Dual surface grommets route power and data cables below the work surface, with under-desk raceway capacity | |
| Clip-on privacy screens | Removable fabric dividers reduce visual distraction between adjacent seated users, no permanent modification required | |
| Integrated modesty panels | Solid panels under each work surface block direct view of seated users' legs for office privacy | |
| Adjustable leveling feet | Threaded feet on central unit base and leg bottoms allow stable setup on uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Creates two dedicated individual work zones without full-height cubicle walls for dense staff layouts | |
|---|---|---|
| Small startup offices | Compact shared footprint offers integrated storage to reduce separate furniture purchases | |
| Shared work hubs | Face-to-face layout supports quick collaboration while maintaining individual visual privacy | |
| Administrative staff zones | Integrated drawers and open shelves provide convenient storage for routine paperwork | |
| Temporary project spaces | Modular knock-down design allows reconfiguration or relocation between office floors |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables dimensional and strength requirements, applies to work surface height and stability | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety requirements for commercial seating and desk use | |
| EN 13986:2004 | Performance specifications for wood-based panels used in furniture construction |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel worksurface and storage components | |
|---|---|---|
| GB/T 3327-2018 | Performance requirements for office desks, applicable to structural stability and load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required E1 grade for interior office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel worksurface and storage components; 2. GB/T 3327-2018: Performance requirements for office desks, applicable to structural stability and load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required E1 grade for interior office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
