Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 1800 x 1400 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Central divider screen height | 350 mm | |
| Single user desktop width | 900 mm | |
| Work surface depth per user | 700 mm | |
| Knee clearance height under desktop | 650 mm | |
| Integrated 4-drawer pedestal dimensions | 600 x 500 x 650 mm | |
| Desktop panel thickness | 25 mm | |
| Divider screen thickness | 20 mm | |
| PVC edge banding thickness | 2 mm | |
| Drawer internal usable depth | 450 mm | |
| Cable management recess opening width | 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Drawer lock cycle rating | 10000 cycles | |
| Workstation net weight | 85 kg | |
| Recommended user capacity | 2 | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Surface stain and water resistance rating | Level 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | E1-grade melamine-faced particleboard (MFC) | |
|---|---|---|
| Support legs and frame | 1.5mm thick powder-coated cold-rolled steel tube | |
| Central divider panel | Wood-grain melamine-faced MDF panel | |
| Drawer fronts | White melamine-faced MFC panels | |
| Pedestal side panel | Dark gray powder-coated steel panel | |
| Edge banding | 2mm thick PVC edge trim applied to all panel cut edges | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Drawer locks | Zinc alloy keyed cam locks, one lock per two drawers | |
| Divider-mounted device stand | Black powder-coated steel wire stand | |
| Leveling feet | Injection-molded nylon adjustable feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Central divider screen | Fixed vertical partition separating adjacent work zones to reduce visual distraction between users | |
|---|---|---|
| Integrated 4-drawer pedestal | Fixed under-desk storage unit with four stacked drawers, two keyed locks for secured document storage | |
| Divider-mounted device holder | Fixed steel cradle positioned at center of divider for holding mobile phones or small tablets at desk level | |
| Cable management recess | Open recessed channel on top of storage pedestal for routing power and data cables from floor to desktop devices | |
| Drawer extension | Full-extension ball-bearing slides allowing 100% drawer access for easy retrieval of stored files and supplies | |
| Floor leveling adjustment | Adjustable nylon feet on all support points to compensate for uneven office floor surfaces | |
| Modesty panel enclosure | Solid dark side panel on pedestal side blocking view of seated user legs from adjacent walkways | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Two-person compact workstation for high-density office seating layouts | |
|---|---|---|
| Small business workspaces | All-in-one desk and storage unit for startup offices with limited floor space | |
| Team collaboration zones | Side-by-side seating for adjacent team members working on shared tasks | |
| Administrative support areas | Stable work surface with lockable storage for administrative and clerical staff | |
| Hot-desking environments | Durable easy-clean surface and secure lockable storage for shared desk setups | |
| Call center workstations | Space-efficient dual-seat layout with visual divider to reduce distraction between agents |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for structural performance validation | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and ergonomic clearance requirements | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction use, formaldehyde emission and performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for pedestal drawer load and cycle durability performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel office desk structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor office use | |
| GB/T 4897.3-2015 | Particleboard specification for furniture-grade panels used in desktop and cabinet construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel office desk structural performance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor office use; 3. GB/T 4897.3-2015: Particleboard specification for furniture-grade panels used in desktop and cabinet construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
