| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 600 x 750 mm | |
|---|---|---|
| Per-user workstation width | 1200 mm | |
| Worktop thickness | 38 mm | |
| Knee clearance height under worktop | 680 mm | |
| Knee clearance width per user | 1100 mm | |
| Mobile pedestal dimensions | 400 x 540 x 654 mm | |
| Cable grommet diameter | 60 mm | |
| Frame leg section width | 45 mm | |
| Partial modesty panel height | 400 mm | |
| Edge band thickness | 2 mm | |
| Caster diameter on pedestals | 51 mm | |
| Leveling foot adjustment height | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static load capacity per workstation | 150 kg | |
|---|---|---|
| File drawer hanging file capacity | 50 kg | |
| Recommended user count | 2 | |
| Worktop Taber abrasion resistance | 500 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Total product net weight | 140 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core | Particleboard core with thermally fused melamine facing | |
|---|---|---|
| Worktop edge | 2mm PVC impact-resistant edge banding | |
| Support frame and legs | Powder-coated steel welded loop construction | |
| Modesty panels | Melamine-faced particleboard, color-matched to worktop | |
| Mobile pedestal body | Cold-rolled steel with powder-coated light gray finish | |
| Drawer slides | Ball-bearing full-extension steel slides | |
| Pedestal casters | Hard nylon swivel casters, 2 with locking brakes | |
| Cable grommets | ABS plastic recessed desk grommets | |
| Leveling feet | Nylon-base adjustable steel threaded feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management access | Two recessed grommets route power/data cables from work surface to floor | |
|---|---|---|
| Mobile pedestal storage | Two lockable 2-drawer units roll freely under each workstation | |
| Seated privacy screening | Partial fixed modesty panels block thigh-level visibility between users | |
| Floor leveling adjustment | Threaded feet at each leg base compensate for uneven floor surfaces | |
| Pedestal mobility lock | Two locking casters per pedestal fix units in place during use | |
| Work surface utility | Smooth non-porous melamine surface resists stains and standard office heat exposure | |
| Pedestal drawer locking | Keyed lock secures both drawers per pedestal for personal storage security | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office work areas | Suitable for two staff side-by-side seating with dedicated personal storage | |
|---|---|---|
| Small business start-up spaces | Compact dual-station design fits limited floor space while providing full work utility | |
| Shared co-working spaces | Lockable pedestal storage supports secure personal storage for rotating users | |
| Administrative team zones | Durable commercial-grade construction supports daily office equipment and document use | |
| Temporary project workspaces | Mobile pedestals can be repositioned to adapt to changing team layouts |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to overall structural performance | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office worktables dimensional safety requirements, applicable to clearance and worktop dimensions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, recommended for structural load and durability verification |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and panel components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and pedestal components | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to worktop and modesty panel core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and panel components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and pedestal components; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to worktop and modesty panel core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
