Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main work surface depth | 900 mm | |
| Side return width | 1800 mm | |
| Side return depth | 500 mm | |
| Tabletop thickness | 50 mm | |
| Seated knee clearance height | 650 mm | |
| Seated knee clearance width | 800 mm | |
| PC tower compartment internal height | 450 mm | |
| Drawer pedestal internal height per drawer | 150 mm | |
| Metal leg section thickness | 50 mm | |
| PVC edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 95 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Recommended user weight for desk use | 136 kg | |
| Net weight | 235 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main work surface | Walnut brown matte melamine laminated engineered wood panel | |
|---|---|---|
| Side return top surface | Light gray matte melamine laminated engineered wood panel | |
| Storage cabinet panels | Dark gray matte melamine laminated engineered wood | |
| Support legs | Powder-coated steel splayed angular frame | |
| Drawer fronts | Dark gray matte melamine with integrated recessed pulls | |
| Edge treatment | 2mm PVC edge banding on all exposed panel edges | |
| Drawer hardware | Steel ball-bearing full-extension drawer slides | |
| Cabinet levelers | Nylon adjustable floor glides at storage base | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual open PC compartments | Two dedicated open bays under return for full-size ATX tower ventilation and access | |
|---|---|---|
| Lockable drawer pedestal | Two-drawer pedestal on side return with central key lock for document security | |
| Integrated under-main-top drawers | Two additional drawers under main work surface for office supply storage | |
| Open return storage shelf | Upper open shelf on side return for document and accessory storage | |
| Cable management grommets | Desktop pass-through grommets for routing monitor and peripheral cables to under-desk space | |
| Splayed leg stability design | Angled front steel leg distributes weight across floor to eliminate desk wobble | |
| Adjustable cabinet glides | Nylon feet on storage return adjust to level desk on uneven office flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Suitable for CEO/manager private offices with large floor space for full L-layout placement | |
|---|---|---|
| Corporate management suite | Matches premium modern office aesthetic for senior leadership workspaces | |
| High-rise commercial office | Pairs with floor-to-ceiling window views in premium urban commercial buildings | |
| Single-user daily office work | Designed for one seated user to conduct document work, computer tasks and meetings | |
| Modern dark-tone office design | Coordinates with dark wall paneling and light wood flooring for contemporary interiors | |
| Workstation with dual monitor setup | Wide main surface supports multi-monitor arms, keyboard and office document layout |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable standard for office worktables, dimensions and mechanical safety requirements | |
|---|---|---|
| EN 15372:2008 | Applicable standard for furniture strength, durability and safety for non-domestic storage units | |
| EN 12521:2015 | Applicable standard for furniture strength, durability and safety requirements for tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk products, defining structural performance and durability test methods | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable standard for storage units, defining performance requirements for integrated drawers |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standard for general technical requirements of wooden furniture, for panel and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Applicable standard for particleboard used in furniture, for core panel structural performance | |
| GB 18580-2017 | Applicable standard for formaldehyde emission limits on wood-based panels, for indoor air quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standard for general technical requirements of wooden furniture, for panel and finish quality; 2. GB/T 4897.3-2003: Applicable standard for particleboard used in furniture, for core panel structural performance; 3. GB 18580-2017: Applicable standard for formaldehyde emission limits on wood-based panels, for indoor air quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
