Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 150 kg | |
|---|---|---|
| Recommended user count | 3 | |
| Product net weight per workstation set | 285 kg | |
| Privacy divider acoustic attenuation | 15 dB | |
| Design service life | 8 years | |
| Surface scratch resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm E1 grade particleboard with walnut-effect melamine laminate, PVC edge banding | |
|---|---|---|
| Pedestal cabinet panels | 18mm E1 grade particleboard with two-tone walnut and off-white melamine finish, teal accent trim | |
| Structural support frame and legs | 1.2mm thick powder-coated matte off-white steel, cylindrical leg profile with leveling feet | |
| Privacy divider panels | 12mm MDF core wrapped in teal woven polyester fabric | |
| Drawer locks and handles | Zinc alloy keyed lock, recessed integrated ABS plastic handle | |
| Leveling feet | 10mm diameter nylon adjustable foot, 15mm vertical adjustment range | |
| Interior cabinet shelves | 18mm E1 grade particleboard with matching melamine finish, fixed position | |
| Accent trim strips | 1mm thick PVC teal colored trim along drawer front top edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Workstation division | Three individual work zones separated by fabric privacy dividers to reduce visual distraction between users | |
|---|---|---|
| Drawer storage security | Keyed lock on upper pedestal drawer to secure personal documents and small office supplies | |
| Equipment storage | Open under-desk bay sized for standard vertical tower CPU placement, no door for unobstructed cabling access | |
| Leveling adjustment | Adjustable nylon feet at each support and cabinet base to compensate for uneven floor surfaces, 15mm total adjustment | |
| Cable management | Reserved cable access cutouts at rear of desktop near divider panels for power and data cord routing | |
| Modular expandability | Linear frame connector system allows addition of matching workstations to extend the run along office layouts | |
| Surface cleaning compatibility | Sealed melamine surface resistant to common office cleaning agents, no staining from accidental coffee or water spills | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | 3-person linear configuration for high-density open office layouts, balancing personal space and team adjacency | |
|---|---|---|
| Small team departments | Suitable for 3-person project teams to support collaborative work with adjacent private storage for each user | |
| Co-working shared workspaces | Durable commercial-grade construction suitable for high-turnover shared office environments with lockable personal storage | |
| Administrative work zones | Standard 750mm work height supports long-duration seated computer work with ergonomic knee clearance | |
| Corporate back office areas | Neutral two-tone finish blends with most commercial office interior design schemes, easy to match with standard mesh office chairs |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to static load and stability verification | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety requirements, applicable to clearance and edge safety verification | |
| EN 13986:2004 | Wood-based panels for construction, applicable to formaldehyde emission and panel structural performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load, durability and stability testing for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet load and cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional accuracy and structural stability testing | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required E1 grade emission ≤0.124mg/m³ for indoor office use | |
| GB/T 3327-2017 | Stability and mechanical performance requirements for desks, applicable to desktop load and drawer testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional accuracy and structural stability testing; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required E1 grade emission ≤0.124mg/m³ for indoor office use; 3. GB/T 3327-2017: Stability and mechanical performance requirements for desks, applicable to desktop load and drawer testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
