Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (L × W × H) | 2800 × 1200 × 1100 mm | |
|---|---|---|
| Worktop height (seated ergonomic) | 750 mm | |
| Per-user work surface width | 1200 mm | |
| Main worktop depth | 600 mm | |
| Side return storage cabinet dimensions | 1600 × 450 × 720 mm | |
| Desktop privacy divider height above worktop | 350 mm | |
| Cork pinboard working area per divider | 1050 × 250 mm | |
| Seated knee clearance height under worktop | 650 mm | |
| Seated knee clearance depth per position | 450 mm | |
| Central under-desk drawer dimensions (per station) | 400 × 500 × 150 mm | |
| Side cabinet open book cubby dimensions | 450 × 300 × 350 mm | |
| A-frame leg splay width at floor | 650 mm | |
| Adjustable leveling foot adjustment range | 15 mm | |
| Main worktop panel thickness | 25 mm | |
| Worktop edge banding thickness | 2 mm | |
| A-frame leg steel tube wall thickness | 1.5 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Worktop distributed static load capacity | 100 kg | |
|---|---|---|
| Drawer slide static load rating per drawer | 30 kg | |
| Recommended maximum user weight per position | 110 kg | |
| Product net weight () | 175 kg | |
| Recommended number of simultaneous users | 2 | |
| Powder coat film thickness on steel frame | 70 microns | |
| Drawer slide cycle durability rating | 50000 open/close cycles | |
| Surface abrasion resistance (melamine worktop) | ≥2000 revolutions (Taber CS-10 wheel, 500g load) | |
| Cabinet hinge cycle durability rating | 80000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm thick E1 grade melamine-faced particleboard with light walnut woodgrain finish | |
|---|---|---|
| Desktop privacy divider frame | 18mm thick particleboard wrapped in brown PU leather-effect laminate | |
| Divider pinboard surface | 5mm thick natural cork sheet over 12mm MDF backing | |
| A-frame support legs | 1.5mm thick welded square steel tube with dark grey matte epoxy powder coat | |
| Cabinet box structure | 18mm thick E1 grade particleboard with dark charcoal grey matte melamine finish | |
| Cabinet door/drawer fronts | 16mm thick MDF with light putty/beige matte melamine finish, matching brown cork-divider trim accent | |
| Worktop edge banding | 2mm thick high-impact ABS edge banding, color-matched to worktop | |
| Drawer slides | 3-section full-extension cold-rolled steel ball-bearing slides with soft-close damping | |
| Locks and handles | Zinc alloy keyed cam locks for top drawer and lower side cabinet drawer, grey ABS integrated pull handles on cabinet doors | |
| Leveling feet | Nylon base with M10 steel threaded screw, adjustable for floor alignment | |
| Cable management components | 0.8mm thick cold-rolled steel under-desk cable tray with 60mm diameter ABS cable grommets at worktop rear | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Desktop pinboard function | Natural cork surface accepts push pins for securing notes, memos, and reference documents within the desk divider frame | |
|---|---|---|
| Storage configuration per station | 1 lockable top personal drawer, 1 lower closed cabinet door, 1 open under-desk CPU/footrest cubby per user position, plus shared side return storage with 2 closed cabinet bays, 1 open book cubby, 1 lower lockable shared drawer | |
| Drawer operation | Soft-close 3-section slides extend drawers 100% of internal depth, with anti-tip interlock to prevent forward furniture tip when fully opened | |
| Locking mechanism | Keyed cam locks secure personal top drawers and shared side storage drawer to secure personal items and confidential documents | |
| Cable management | Central under-desk cable channel with pass-through cutouts at worktop rear for routing power and data cables to desktop equipment | |
| Stability bracing | Horizontal steel cross-brace connects the two legs of each A-frame support to prevent lateral wobble and increase frame rigidity | |
| Floor leveling | Adjustable screw feet on all legs and cabinet bases allow ±15mm height adjustment to compensate for uneven office flooring | |
| Modular expandability | Unit is designed to connect end-to-end with identical workstation modules to form 4-person, 6-person, or longer linear bench workstations | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Flat pack carton count | 3 cartons | |
|---|---|---|
| Worktop and divider carton dimensions | 2850 × 680 × 110 mm | |
| Cabinet panel carton dimensions | 1650 × 760 × 180 mm | |
| Hardware and leg carton dimensions | 700 × 250 × 180 mm | |
| Total packaged gross weight | 190 kg | |
| Total packed volume (CBM) | 0.42CBM | |
| Assembly time (two person install team) | 180 minutes | |
| Packaging materials | 5-layer corrugated export cartons, EPS foam corner protectors, EPE foam wrap for panel surfaces, sealed polybag for hardware kit, printed assembly manual | |
| 40ft HQ container loading quantity (KD packed) | 95units | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Suitable for 2 adjacent employees in open office layouts, providing visual privacy via the pinboard divider and personal storage without full-height partition walls | |
|---|---|---|
| Small business/startup office spaces | All-in-one design integrates work surfaces, personal storage, and shared reference storage to minimize footprint for teams with limited square footage | |
| Corporate team and department zones | Modular construction allows linear extension to create longer bench systems for sales, admin, design, or operations teams in formal corporate offices | |
| Coworking and shared office spaces | Lockable drawers secure personal belongings for rotating users, while pinboard surfaces support temporary note-taking for short-term workspace users | |
| Design and architecture studio workspaces | Open side cubby stores reference books and materials, while cork dividers allow pinning sketches, mood boards, and project notes for design work | |
| Recommended matching chair specification | Pair with mid-back ergonomic task chairs with 520 mm adjustable seat height to align with the 750mm fixed worktop height for ergonomic seated use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks - Part 1: Dimensions: applies to worktop height, knee clearance, and dimensional ergonomic requirements for seated office use | |
|---|---|---|
| EN 527-2:2002+A1:2003 | Office work tables and desks - Part 2: Mechanical safety requirements: applies to structural stability, edge safety, and load requirements | |
| EN 15372:2016 | Furniture - Strength, durability and safety - Requirements for non-domestic storage furniture: applies to cabinet and drawer structural performance for commercial office use | |
| EN 13986:2004+A1:2015 | Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking: applies to structural panel performance for cabinet and worktop components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Desks and Tables: applies to static load, stability, durability, and surface performance requirements for commercial workstations supplied to North American markets | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units: applies to drawer slide cycle testing, shelf load, anti-tip performance, and lock durability for integrated cabinet components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture: applies to dimensional tolerances, edge safety, static load requirements, and formaldehyde emission limits for all wood-based panel components of this workstation | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture: applies to weld strength, powder coating adhesion, and corrosion resistance for the steel A-frame leg components | |
| GB 18580-2017 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels and finishing products: applies to E1 grade (≤0.124mg/m³) formaldehyde emission requirements for all particleboard/MDF components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables: applies to 100kg distributed static load, 450mm drop impact resistance, and 40kg lateral stability testing for the worktop and leg assembly to prevent tip-over | |
| GB/T 10357.5-2011 | Furniture mechanical performance test for storage units: applies to drawer slide durability, shelf load, and anti-tip stability for cabinet components | |
| Worktop edge radius | R8 mm |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture: applies to dimensional tolerances, edge safety, static load requirements, and formaldehyde emission limits for all wood-based panel components of this workstation; 2. GB/T 3325-2017: General technical requirements for metal furniture: applies to weld strength, powder coating adhesion, and corrosion resistance for the steel A-frame leg components; 3. GB 18580-2017: Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels and finishing products: applies to E1 grade (≤0.124mg/m³) formaldehyde emission requirements for all particleboard/MDF components; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables: applies to 100kg distributed static load, 450mm drop impact resistance, and 40kg lateral stability testing for the worktop and leg assembly to prevent tip-over; 5. GB/T 10357.5-2011: Furniture mechanical performance test for storage units: applies to drawer slide durability, shelf load, and anti-tip stability for cabinet components; 6. Worktop edge radius: R8 mm; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
