Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall unit dimensions | 2800 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Per-user work position width | 1400 mm | |
| Work surface depth | 600 mm | |
| Desktop panel thickness | 25 mm | |
| Cabinet and hutch panel thickness | 16 mm | |
| PVC edge band thickness | 2 mm | |
| Privacy divider height above desk | 350 mm | |
| Under-desk knee clearance height | 620 mm | |
| Under-desk CPU compartment dimensions | 250 x 500 x 450 mm | |
| Rear upper hutch shelf height | 1100 mm | |
| Drawer internal usable dimensions | 400 x 500 x 120 mm | |
| Lower storage cabinet internal dimensions | 400 x 500 x 550 mm | |
| Slanted steel leg section size | 50 x 30 mm | |
| Cross-brace support bar thickness | 1.5 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 120 kg | |
|---|---|---|
| Metal frame static load rating | 200 kg | |
| Unit net weight | 120 kg | |
| Recommended user capacity | 2 people | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Cabinet door hinge cycle rating | 80000 open/close cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Factory warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and storage panels | E1 grade melamine-faced particleboard | |
|---|---|---|
| Desk frame and legs | Powder-coated white tubular steel | |
| Front cross support brace | Powder-coated olive green steel | |
| Privacy divider screen | Melamine-faced panel with polished steel support posts | |
| Edge trim | 2mm thick PVC edge banding | |
| Hardware components | Zinc-plated steel screws, locks, hinges and ball-bearing slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Dual separated work zones | Central privacy divider splits surface into two independent work positions | |
|---|---|---|
| Under-desk CPU storage bays | Two open divided compartments positioned under work surface | |
| Right-side enclosed storage | One upper drawer and one lower hinged cabinet door with integrated lock | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff areas | Dual-station layout efficiently accommodates two employees with personal storage | |
|---|---|---|
| Small business and startup offices | Integrated hutch and cabinet reduce need for separate ancillary storage furniture |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and performance requirements for commercial workstations | |
|---|---|---|
| EN 13722:2004 | Office furniture, storage cabinets, performance requirements for integrated cabinet components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable for load, durability and stability testing of work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for storage units, applicable for drawer and cabinet performance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade requirement for indoor office use | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable for desktop and frame load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel construction and finish quality; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade requirement for indoor office use; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable for desktop and frame load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
