Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 1554 x 1200 x 1100 mm | |
|---|---|---|
| Worksurface height from floor | 750 mm | |
| Individual work surface depth | 600 mm | |
| Worksurface panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Desktop privacy divider dimensions | 1200 x 300 x 20 mm | |
| Integrated storage partition height | 1100 mm | |
| Upper open shelf compartment height | 300 mm | |
| Minimum seated knee clearance height under desk | 670 mm | |
| Splayed steel leg tube cross-section | 50 x 50 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Whole workstation net weight reference | 126 kg | |
|---|---|---|
| Per work surface static load capacity | 120 kg | |
| Lockable drawer dynamic load rating | 30 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Cabinet door hinge cycle durability | 80000 cycles | |
| Upper open shelf static load per compartment | 20 kg | |
| Recommended supported user count | 2 | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Product warranty duration | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface panels | E1 grade melamine-faced particleboard | |
|---|---|---|
| Storage partition cabinet carcass | 18mm thick melamine-faced MDF | |
| Desktop privacy divider | Fabric-wrapped fiberboard core | |
| Angled support legs | Powder-coated square steel tubing | |
| Edge protection | 2mm thick impact-resistant PVC edge banding | |
| Lower cabinet door panels | Matte white powder-coated steel | |
| Open shelf trim accents | Light oak wood-veneer laminated MDF | |
| Hardware components | Zinc-plated steel screws, connectors and lock cylinders | |
| Cable management raceway | ABS plastic channel | |
| Foot glides | Nylon height-adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dual-position work layout | Two side-by-side seated workstations separated by a low central storage partition | |
|---|---|---|
| Lockable storage security | Keyed cylinder locks on lower cabinet doors and utility drawers | |
| Desktop privacy screening | Brown fabric divider panel mounted between adjacent work surfaces | |
| Cable management routing | 60mm diameter desk grommets connected to internal ABS raceway | |
| Modular expandability | Pre-drilled connection points on partition sides | |
| Smooth drawer operation | Full-extension silent ball-bearing drawer slides | |
| Height-adjustable leveling | 10mm adjustable range on nylon foot glides | |
| Lower lockable cabinet front width | 450 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan corporate offices | Designed for dense team seating with zoning via low integrated storage partitions | |
|---|---|---|
| Startup and co-working spaces | Modular layout allows reconfiguration to match changing team size requirements | |
| Government and administrative work areas | Lockable storage supports secure document storage for frontline staff | |
| Staff work zones adjacent to meeting areas | Low partition height maintains visual connection while providing personal privacy | |
| Recommended pairings | Match with ergonomic mid-back task chairs and under-desk cable management trays |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to commercial worktop load testing | |
|---|---|---|
| EN 15372:2016 | Durability and stability requirements for office storage furniture, applicable to cabinet components | |
| EN 13722:2004 | Furniture strength and durability testing for office storage units, applicable to shelf load ratings |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to work surface and leg structural testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to cabinet, drawer and shelf durability | |
| ANSI/BIFMA X5.1-2017 | General office furniture safety requirements, applicable to stability and edge safety checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MFC/MDF cabinet and worktop components | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks and workstations, applicable to work surface strength testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel material acceptance | |
| GB/T 4897.3-2015 | Specification for particleboard used in furniture, applicable to worktop core material requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MFC/MDF cabinet and worktop components; 2. GB/T 3327-2017: Performance requirements for office desks and workstations, applicable to work surface strength testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel material acceptance; 4. GB/T 4897.3-2015: Specification for particleboard used in furniture, applicable to worktop core material requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
