Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2800 x 1200 x 1100 mm | |
|---|---|---|
| Desktop work surface height | 750 mm | |
| Single individual workstation width | 700 mm | |
| Single individual workstation depth | 600 mm | |
| Central privacy divider height above desktop | 350 mm | |
| Under-desk knee clearance height | 620 mm | |
| Desktop panel thickness | 25 mm | |
| Storage pedestal panel thickness | 18 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel cantilever leg wall thickness | 1.2 mm | |
| Integrated cable grommet diameter | 80 mm | |
| Drawer internal usable depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total workstation net weight | 100 kg | |
|---|---|---|
| Desktop static uniform load capacity | 120 kg | |
| Hinge and slide cycle durability | 50000 cycles | |
| Maximum recommended user weight per station | 110 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Product warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop work surface | E1 grade melamine-faced high-density particleboard | |
|---|---|---|
| Storage cabinet and drawer panels | E1 grade melamine-faced particleboard | |
| Support frame and legs | Powder-coated white cold-rolled steel | |
| Central privacy dividers | Fabric-covered acoustic panel with terracotta and light grey finish | |
| Edge protection | 2mm thick PVC edge banding | |
| Drawer and cabinet hardware | Zinc-plated steel locks, hinges and ball-bearing slides | |
| Leveling feet | Nylon-tipped adjustable steel glides | |
| Integrated power module housing | Flame-retardant ABS plastic | |
| Divider support rails | Anodized aluminum alloy | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Workstation configuration | Dual-row face-to-face layout for 4 seated staff | |
|---|---|---|
| Per-station storage | 1 lockable top drawer + 2 lower cabinet compartments per user | |
| Cable management | Central integrated power outlets plus desktop cable passthroughs | |
| Privacy screen function | Fabric acoustic dividers reduce visual distraction between seats | |
| Assembly type | Knock-down flat-pack construction with bolted connections | |
| Adjustment features | Threaded leveling feet at each leg base | |
| Customization compatibility | Modular design supports connection to additional workstation units | |
| Surface utility | Smooth non-porous melamine surface supports wet wiping | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Suitable for 4-person team work zones in corporate offices | |
|---|---|---|
| Startup and small business workspaces | Cost-effective modular solution for growing teams with shared infrastructure | |
| Call center and administrative departments | Divider screens provide privacy for focused individual task work | |
| Co-working space dedicated team zones | Durable commercial construction supports high-frequency daily use | |
| Back-office operational work areas | Lockable storage meets personal item security requirements for staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables - Safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables - Mechanical safety test methods | |
| EN 13986:2004 | Wood-based panels for structural use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Safety and durability standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Safety and performance standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2016: Performance test methods for office desks; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
