PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Static desktop load capacity	80 kg
Recommended user capacity	1 person
Product net weight	95 kg
Packaged gross weight	110 kg
Panel service load duration	8 hours daily
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test
Recommended Procurement Warranty	Structure 5 years; hardware 3 years; finish 2 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop and worktop	25 mm engineered wood panel with walnut wood-grain melamine surface and sealed edge banding
Storage cabinet	Melamine-faced engineered wood carcass with vertical walnut grain exterior and dark interior panels
Upper hutch	Rectangular engineered wood storage box with open cubby and wood-grain exterior
Support legs	Dark powder-coated round metal tube legs with floor-contact glides
Modesty and side panels	Dark composite panel beneath the main work surface
Hardware	Lock on pedestal side, drawer slides, hinges, and adjustable floor glides

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Work layout	L-shaped workflow provides a 1400 mm main task zone and a 1200 mm return for storage, printer, or reference documents.
Storage function	Left floor pedestal supports the return and provides lockable document storage with a visible side lock position.
Overhead organization	Low hutch includes an open compartment for books and binders while retaining side-return work surface access.
Cable and monitor layout	Rear desktop divider creates a monitor placement and cable-routing zone between the screen and back edge.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Total packed volume	0.32 m3
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Private executive office	Suits managers and professionals requiring a main computer zone plus return storage for documents, printer, and reference materials.
Supervisor or administrative workstation	Provides lockable storage and a compact L-shaped footprint for daily paperwork, laptop use, and filing within one workstation.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LDS-WAL-1800-HUTCH

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LDS-WAL-1800-HUTCH

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LDS-WAL-1800-HUTCHOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The L-Shaped Executive Workstation with Storage Hutch combines a structured office footprint with integrated storage, presenting a practical solution for users who need task space, filing, and overhead organization in one coordinated unit. Its walnut-look engineered wood surfaces and dark metal support elements create a professional contrast between warm wood-grain detailing and a restrained dark frame, suited to conventional private offices as well as focused administrative settings. Model LDS-WAL-1800-HUTCH is supplied as an unbranded executive desk and workstation. Visually, the workstation follows an L-shaped layout. The main task zone provides the primary computer and writing area, while the return offers space for storage, a printer, or reference documents. A low rectangular hutch sits above the work area with an open cubby for books and binders, while preserving access to the side-return surface. At the rear, a desktop divider establishes a monitor and cable-routing zone between the screen and the back edge, helping the desktop remain ordered. A dark modesty panel beneath the main surface reinforces the tailored office appearance. The desktop and worktop use a 25 mm engineered wood panel with a walnut wood-grain melamine surface and sealed edge banding; the finished top thickness is 50 mm. Storage components use melamine-faced engineered wood, with vertical walnut grain on the cabinet exterior and dark interior panels. The left floor pedestal supports the return and includes lockable document storage with a visible side lock. Rounded dark powder-coated metal tube legs, fitted with floor-contact glides, support the desk. Hardware includes drawer slides, hinges, the pedestal lock, and adjustable floor glides. Functionally, the layout is designed for one user. Each main seat position offers 680 mm of knee clearance height and 900 mm of width. The desktop has a static load capacity of 80 kg, with a separate reference value of 150 kg uniformly distributed across the top. Drawer slides are rated for 45 kg per pair and 50,000 cycles. An 80 mm cable opening and a 120 mm deep cable tray support cable management. The panel service load duration is rated for eight hours of daily use. This workstation is appropriate for a private executive office where a manager or professional needs a dedicated computer zone alongside return-based storage. It also suits a supervisor or administrative workstation handling daily paperwork, laptop use, and filing. Procurement teams should plan for two cartons as the reference package count, while noting the supplied logistics information also records larger reference packaging data in four cartons. Assembly time is referenced at 40 minutes per set, and the product should be specified for single-user operation with lockable storage requirements confirmed before purchase.
