Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 1100 × 1120 mm | |
|---|---|---|
| Main work surface height | 760 mm | |
| Desktop panel thickness | 25 mm | |
| Knee clearance height under main work surface | 720 mm | |
| Knee clearance width under main work surface | 800 mm | |
| Upper hutch open shelf height | 280 mm | |
| Drawer internal usable height | 120 mm | |
| Lower cabinet interior height | 600 mm | |
| U-shaped metal leg tubing section | 40 x 40 mm | |
| Cable grommet diameter | 60 mm | |
| Open shelf depth | 300 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 55 kg | |
|---|---|---|
| Product net weight | 37 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Recommended maximum user load for seated work | 110 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface panels | E1-grade particle board with white melamine laminate | |
|---|---|---|
| Storage cabinet and hutch panels | E1-grade particle board with matching white laminate | |
| U-shaped support leg | Powder-coated steel tubing with white finish | |
| Edge banding | 1mm thick PVC edge trim on all exposed panel edges | |
| Drawer slides | Cold-rolled steel side-mount ball-bearing slides | |
| Cabinet door hinge | Cold-rolled steel concealed hinge | |
| Adjustable foot pads | Non-slip PP plastic foot pads under base | |
| Cable grommet | ABS plastic round cable grommet | |
| Handle hardware | Recessed metal pull handles with dark finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management grommet | Single 60mm grommet routes monitor and peripheral cables through desktop | |
|---|---|---|
| Upper hutch open storage | Three divided open shelves for books, decor and frequently used items | |
| Lower drawer storage | One full-width drawer for stationery and small office supply organization | |
| Enclosed lower cabinet | One hinged-door cabinet for concealed storage of CPU or documents | |
| Leveling adjustment | Small adjustable feet compensate for uneven floor surfaces | |
| Corner space utilization | L-shaped layout fits 90-degree wall corners to maximize floor space | |
| Cantilever work surface support | U-frame leg provides unobstructed knee space under the main desktop | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office private workspace | Fits corner positions for 1-person remote work and study use | |
|---|---|---|
| Student study room | Provides combined work surface and storage for school supplies and books | |
| Small apartment multi-use room | Space-saving L-shape fits tight corner areas without excess floor use | |
| Small startup office workstation | Low-cost practical setup for entry-level employee workstations | |
| Bedroom work nook | White minimalist finish matches neutral bedroom decor schemes |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particle board performance requirements for furniture construction | |
|---|---|---|
| EN 527-1:2011 | Office work desk dimensional and safety requirements | |
| EN 14749:2016 | Safety requirements for domestic and office storage furniture |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for office desks and work surfaces |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture for office use | |
|---|---|---|
| GB/T 4897.3-2003 | Particle board specifications for furniture-grade panel use | |
| GB 18580-2017 | Formaldehyde emission limits for interior decoration wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture for office use; 2. GB/T 4897.3-2003: Particle board specifications for furniture-grade panel use; 3. GB 18580-2017: Formaldehyde emission limits for interior decoration wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
