Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2400 x 600 x 750 mm | |
|---|---|---|
| Worktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Central privacy divider dimensions | 2300 x 30 x 480 mm | |
| Seated knee clearance height under worktop | 660 mm | |
| Under-desk knee clearance depth | 570 mm | |
| Cantilever steel frame tube section | 50 x 50 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Cable management slot width | 80 mm | |
| Caster wheel diameter on pedestals | 50 mm | |
| Frame wall thickness | 1.2 mm | |
| Pedestal top drawer internal height | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Whole desk net weight | 68 kg | |
|---|---|---|
| Worktop uniform static load capacity | 135 kg | |
| Recommended seated user capacity | 2 people | |
| Drawer slide cycle durability | 50000 cycles | |
| Hinge and lock mechanism cycle durability | 20000 cycles | |
| Worktop surface abrasion resistance | 2000 cycles | |
| Product structural warranty | 5 years | |
| Available finish options | 8 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E1 grade particleboard with white melamine laminate finish | |
|---|---|---|
| Worktop edge protection | 2mm thick PVC edge banding, rounded profile | |
| Support frame | Cold-rolled steel with white epoxy powder coating | |
| Privacy divider core | High-density fiberboard wrapped in gray acoustic fabric | |
| Mobile pedestal body | 0.8mm thick cold-rolled steel with white powder coating | |
| Pedestal drawer slides | Full-extension ball-bearing steel slides | |
| Pedestal caster wheels | Black nylon swivel casters, two lockable per unit | |
| Top drawer lock mechanism | Digital combination lock with LED indicator | |
| Frame leveling feet | Black nylon adjustable glides at all frame ground contact points | |
| Cable management components | ABS plastic cable slot grommets and under-desk steel cable tray | |
| Screen mounting brackets | Stamped steel brackets with white powder-coated finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Side-by-side work zoning | Central fabric divider creates two separated private work zones for adjacent users | |
|---|---|---|
| Cable routing access | Integrated rear central cable slot allows power and data cables to pass from worktop to under-desk tray | |
| Pedestal mobility | Mobile pedestals mount on four swivel casters, allowing repositioning under either work position | |
| Drawer locking security | Digital combination lock secures the top pedestal drawer for personal storage security | |
| Frame leveling adjustment | Adjustable nylon glides at frame legs compensate for uneven floor surfaces | |
| Screen utility | Fabric-covered divider supports pinning of notes and documents, and reduces cross-talk between users | |
| Pedestal storage configuration | Each pedestal includes one shallow stationery drawer and one deep filing drawer for A4 documents | |
| Modular expandability | Cantilever frame design allows connection to additional matching workstations for larger open-office layouts | |
| Knee space access | Open cantilever frame has no front crossbar, providing unobstructed leg room for seated users | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Provides space-efficient dual work positions with acoustic/visual privacy between coworkers | |
|---|---|---|
| Small business startup offices | Compact integrated workstation with included storage requires minimal floor space for two staff | |
| Coworking space flexible zones | Modular design allows reconfiguration, and lockable pedestals support secure hot-desking use | |
| Administrative department work areas | Stable work surface and ample under-desk storage supports daily paperwork and computer work | |
| Project team work clusters | Can be connected to additional matching units to form larger 8person work pods |
EU Market Access Requirements* EN Standards
| EN 527-2:2016 | Applies to safety, strength and durability requirements for office work desks and workstations | |
|---|---|---|
| EN 1335-1:2020 | Covers dimensional coordination between office desks and task chairs for ergonomic seated use | |
| EN 1022:2018 | Specifies stability test methods for seating-adjacent office storage and desk units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to performance and durability test standards for commercial office desk products | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Covers performance requirements for mobile storage pedestals used with office desks |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden office furniture including worktop strength and finish durability | |
|---|---|---|
| GB/T 3327-2016 | Covers dimensional stability and structural performance requirements for office desk products | |
| GB 18580-2017 | Specifies formaldehyde emission limits for wood-based panel components used in indoor office furniture | |
| GB/T 10357.1-2013 | Defines test methods for mechanical strength and stability of tables used in office environments |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden office furniture including worktop strength and finish durability; 2. GB/T 3327-2016: Covers dimensional stability and structural performance requirements for office desk products; 3. GB 18580-2017: Specifies formaldehyde emission limits for wood-based panel components used in indoor office furniture; 4. GB/T 10357.1-2013: Defines test methods for mechanical strength and stability of tables used in office environments; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
