Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 2400 x 1100 mm | |
|---|---|---|
| Seated work surface height | 750 mm | |
| Single individual desktop size | 1200 x 600 mm | |
| Desktop privacy divider height | 350 mm | |
| Central storage pedestal size | 1200 x 600 x 1100 mm | |
| Under-desk seated knee clearance height | 650 mm | |
| Under-desk knee clearance depth | 500 mm | |
| Desktop thickness | 25 mm | |
| PVC edge band thickness | 3 mm | |
| Steel leg wall thickness | 1.5 mm | |
| Cable grommet diameter | 80 mm | |
| Drawer internal usable dimensions | 450 x 500 x 150 mm | |
| Open shelf internal height | 250 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Recommended maximum user weight per seat | 120 kg | |
| Surface scratch resistance rating | 2H pencil hardness | |
| Surface water resistance | Sealed non-porous finish | |
| Product net weight | 150 kg | |
| Warranty period | 3 years | |
| Available color options | 30+ finishes | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm melamine-faced MFC particleboard | |
|---|---|---|
| Edge trim | 3mm thermally fused PVC edge banding | |
| Support legs | 1.5mm thick powder-coated dark gray steel | |
| Central storage cabinet carcass | 15mm melamine-faced engineered board | |
| Drawer fronts | 15mm light wood melamine-faced engineered board | |
| Desktop privacy dividers | 18mm wood-based panel with wood-grain finish | |
| Storage shelves | 15mm dark melamine-faced engineered board | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Hardware connectors | Zinc-plated steel cam-lock and screw fittings | |
| Feet pads | Injection-molded non-slip PP plastic | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 2x2 face-to-face 4-person layout | |
|---|---|---|
| Desktop privacy screening | Low mounted dividers between adjacent seats | |
| Cable management | Recessed grommet per work surface | |
| Central storage | 2 lockable drawers and 2 open shelves | |
| Drawers | Full-extension steel slide operation | |
| Assembly design | Knock-down flat-pack construction | |
| Desk leveling | Adjustable foot pads on each leg and pedestal | |
| Modular compatibility | Connectable to additional matching workstations | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Suits 4-person team clusters with built-in shared and personal storage | |
|---|---|---|
| Small business office layouts | Compact footprint maximizes seating for limited square footage | |
| Startup co-working spaces | Modular design supports flexible team arrangements and shared use | |
| Corporate administrative departments | Durable construction withstands daily high-traffic office use | |
| Call center work areas | Privacy dividers reduce visual distraction between adjacent workers | |
| Temporary project team spaces | Knock-down design allows easy reconfiguration and relocation |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables mechanical safety test methods | |
| EN 13986:2004 | Wood-based panels for construction formaldehyde limits |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2018 | Office desk and table performance requirements | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2018: Office desk and table performance requirements; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
