Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1850 x 1500 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Desktop thickness | 30 mm | |
| Storage return unit height | 1100 mm | |
| Work surface depth | 700 mm | |
| Seated knee clearance height under work surface | 620 mm | |
| Seated knee clearance width | 700 mm | |
| CPU compartment internal dimensions | 250 x 500 x 450 mm | |
| Upper open shelf compartment height | 320 mm | |
| Double-door cabinet internal height | 400 mm | |
| Desktop privacy divider height above work surface | 300 mm | |
| Edge banding thickness | 2 mm | |
| Steel leg tube wall thickness | 1.5 mm | |
| A-leg footprint spread at floor | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Desktop static load capacity | 145 kg | |
|---|---|---|
| Recommended maximum user weight for seated use | 113 kg | |
| Leveling foot adjustment range | 15 mm | |
| Lacquer finish abrasion resistance | 2000 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Product net weight | 78 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface and storage panels | E0-grade low-emission engineered wood with matte cream lacquer finish | |
|---|---|---|
| Support leg frame | Powder-coated steel with terracotta accent insert at apex joint | |
| Desktop privacy divider | Polyester fabric upholstered rigid panel with brown finish | |
| Edge banding | 2mm thick PVC impact-resistant edging matching cream panel finish | |
| Drawer slide hardware | Cold-rolled steel ball-bearing full-extension slides with integrated lock | |
| Cabinet door hinges | Cold-rolled steel soft-close concealed hinges | |
| Foot levelers | Nylon base adjustable threaded levelers on storage unit and legs | |
| Cable management grommet | ABS plastic flip-top grommet fitted to work surface | |
| Drawer and door pulls | Integrated recessed metal pulls with matte black finish | |
| Upper shelf accent panel | Engineered wood with warm brown laminate finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Left return storage configuration | Two upper open display shelves, one central lockable drawer, lower double-door closed cabinet, dedicated open CPU bay | |
|---|---|---|
| Desktop privacy divider | Fixed upholstered panel mounted along rear work surface to block seated cross-visibility | |
| Leveling adjustment | Threaded nylon feet on storage base and A-leg to compensate for uneven floor surfaces | |
| Lockable storage | Central drawer fitted with key lock to secure confidential documents and valuables | |
| Cable management | Flip-top desk grommet routes power and data cables from work surface to floor | |
| CPU storage bay | Open under-desk compartment sized for full-size desktop towers with front and rear ventilation | |
| A-frame leg support | Angled steel free-end leg eliminates cross-brace obstruction to leg room under work surface | |
| Storage door operation | Double hinged doors swing open to access full-width lower cabinet storage | |
| Drawer operation | Full-extension ball-bearing slides allow complete access to drawer contents | |
| Lockable drawer internal height | 120 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Provides extended work surface and integrated storage for senior staff daily task work | |
|---|---|---|
| Home office workspace | Combines work area, book storage and PC storage for remote work use in residential settings | |
| Small open-plan workstation | Included privacy divider reduces visual distraction in shared open office environments | |
| Home study room | Warm neutral finish and storage capacity support study, writing and hobby activities | |
| Startup office workstation | Integrated storage eliminates need for separate filing cabinets, reducing space requirements | |
| Consulting room workspace | Lockable drawer secures confidential client documents during consultation sessions |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural stability testing | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables dimension and performance requirements, applicable to work surface height and clearance | |
| EN 13722:2004 | Furniture strength and durability for storage units, applicable to cabinet, drawer and shelf performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer, shelf and cabinet load and cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to panel construction and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for wood-based furniture, applicable to E0-grade engineered wood panels | |
| GB/T 10357.1-2013 | Mechanical performance test for desks, applicable to desktop and shelf load rating verification | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable to structural panel substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to panel construction and finish quality; 2. GB 18584-2001: Limit of formaldehyde emission for wood-based furniture, applicable to E0-grade engineered wood panels; 3. GB/T 10357.1-2013: Mechanical performance test for desks, applicable to desktop and shelf load rating verification; 4. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable to structural panel substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
