PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2400 × 1200 × 750 mm
Individual workstation width	1200 mm
Individual workstation depth per side	600 mm
Under-desk knee clearance height	720 mm
Privacy divider height	400 mm
Central storage pedestal dimensions	1200 x 400 x 650 mm
Worktop thickness	25 mm
Steel leg profile thickness	1.5 mm
Steel support beam size	50 x 25 x 1.5 mm
Edge banding thickness	2 mm
Drawer interior height per pedestal	120 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total set net weight	160 kg
Distributed load per work position	80 kg
Load per storage drawer	25 kg
Recommended user capacity	4 people
Worktop abrasion resistance	2000 cycles
Frame coating corrosion resistance lifespan	5 years
Warranty for structural components	5 years
Warranty for hardware and moving parts	3 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worktop surface	E1 grade melamine-faced chipboard, anti-scratch, anti-stain, water-resistant
Worktop edge trim	2mm thick PVC edge banding, impact-resistant
Leg and frame structure	1.5mm thick cold-rolled steel, matte dark gray powder-coated finish
Support cross beams	50x25x1.5mm rectangular steel tube, powder-coated, welded connections
Privacy dividers	18mm thick wood-based composite panel, brown wood-grain finish
Divider mounting brackets	Black powder-coated steel, fixed to worktop surface
Storage pedestal body	18mm thick melamine panel, dark gray side panel, white drawer fronts
Drawer slides	Cold-rolled steel 3-section full-extension ball-bearing slides
Pedestal support legs	20mm diameter angled steel legs, dark powder-coated finish
Cable grommets	Black ABS plastic recessed cable ports at each work position
Leveling feet	Nylon adjustable glides on each leg base, for uneven floor adjustment
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Workstation layout	Back-to-back face-to-face arrangement for 4 staff, divided by two central privacy screens
Privacy separation	Low mounted dividers block direct line of sight between opposite seated users, 400mm above worktop
Cable management	Recessed ABS grommets at each position route monitor/power cables below work surface
Central storage access	4-drawer central pedestal provides shared stationery/filing storage, accessible from both seating sides
Drawer locking	Two integrated key locks secure upper and lower drawer sets for document security
Floor leveling	Adjustable nylon feet on each leg compensate for uneven office flooring, 10mm adjustment range
Modular expansion	Bench frame design supports connection to adjacent matching workstation sets for open-plan layouts
Surface maintenance	Smooth melamine finish requires only damp cloth cleaning, resists common office coffee/ink stains
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office staff areas	Suitable for 4-person team clusters in corporate open-plan workspaces, supports collaborative work
Small business work zones	Ideal for startup and SME offices needing compact 4-seat layout with shared storage
Administrative workstations	Suitable for admin, data entry, and customer service teams needing separated work surfaces
Co-working flexible spaces	Fits co-working operator layouts for dedicated team desks, modular design supports reconfiguration
Government and institutional offices	Compliant with commercial furniture durability standards for long-term daily office use
Call center seating clusters	Supports four call center positions with cable management for headsets and monitors

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Applicable to safety and dimensional requirements for office work desks
EN 527-2:2002	Applicable to mechanical strength and stability test methods for office desks
EN 13986:2004	Applicable to wood-based panel formaldehyde emission for construction/furniture use

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Applicable to safety and durability testing for office desks
ANSI/BIFMA e3-2019	Applicable to furniture sustainability and material emission criteria

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	Applicable to general technical requirements for wooden office furniture
GB/T 3327-2020	Applicable to dimensional and stability requirements for office desks
GB 18580-2017	Applicable to formaldehyde emission limits for wood-based panels
GB/T 24821-2009	Applicable to structural strength and durability for office tables

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: Applicable to general technical requirements for wooden office furniture;
2. GB/T 3327-2020: Applicable to dimensional and stability requirements for office desks;
3. GB 18580-2017: Applicable to formaldehyde emission limits for wood-based panels;
4. GB/T 24821-2009: Applicable to structural strength and durability for office tables;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFW-4P-2400-BENCH-DIV

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFW-4P-2400-BENCH-DIV

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFW-4P-2400-BENCH-DIVOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This unbranded 4-Person Face-to-Face Open-Plan Office Bench Workstation (model OFW-4P-2400-BENCH-DIV) presents a streamlined, modern aesthetic tailored for collaborative open work environments. Designed in a back-to-back, face-to-face configuration, the unit seats four users across two opposite sides, split by low, brown wood-grain privacy dividers mounted 400 mm above the work surface to block direct line of sight between seated opposite users without blocking cross-team communication. The overall unit measures 2400 x 1200 x 750 mm, with each individual work position offering 1200 mm of width and 600 mm of depth, paired with 720 mm of clear under-desk knee space for comfortable seated use. The 25 mm thick worktop is constructed from E1 grade melamine-faced chipboard, finished with anti-scratch, anti-stain, water-resistant surfacing and 2 mm thick impact-resistant PVC edge banding. The support structure uses 1.5 mm thick cold-rolled steel for legs and 50x25x1.5 mm rectangular steel tube cross beams with welded connections, all coated in a matte dark gray powder finish rated for 5 years of corrosion resistance. A central 1200 x 400 x 650 mm storage pedestal sits between the two work surface rows, built with 18 mm thick melamine panels featuring dark gray sides and white drawer fronts, supported by angled dark powder-coated steel legs. Four full-extension drawers run on cold-rolled steel 3-section ball-bearing slides, with two integrated key locks to secure upper and lower drawer sets for shared document and stationery storage accessible from both seating sides. Functional details include recessed ABS cable grommets at each position to route power and monitor cables below the work surface, and adjustable nylon feet on every leg that offer 10 mm of adjustment to compensate for uneven flooring. The bench frame is designed for modular connection to adjacent matching units to scale with growing team layouts. Each work position supports a distributed load of 80 kg, while each storage drawer holds 25 kg, and the worktop delivers 2000 cycles of abrasion resistance for daily commercial use; structural components carry a 5-year warranty. This workstation is well suited for 4-person team clusters in corporate open-plan offices, compact work zones for startups and small to medium enterprises, administrative and data entry teams, co-working dedicated team areas, government and institutional office spaces, and call center seating clusters, as it balances personal privacy, easy collaboration, and integrated shared storage. Procurement teams should note that each unit ships across multiple cartons with a total packaged gross weight of 180 kg and 1 m³ total packaging volume, requires 40 minutes of assembly time per set, and supports seamless connection to matching units to build larger open-plan seating layouts as space needs evolve.

4-Person Face-to-Face Open-Plan Office Bench Workstation with Central Storage Pedestal Specifications
