Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total desktop static load capacity | 113 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Cable grommet inner diameter | 60 mm | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Net product weight | 92 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | E1 grade MDF core with dark wood-grain laminate finish, 32mm thick | |
|---|---|---|
| Desk legs | Powder-coated tapered splayed steel, 50mm diameter, matte black finish | |
| Privacy divider | Fabric-wrapped acoustic panel over MDF core, dark grey finish | |
| Storage cabinet panels | 16mm thick laminated engineered board with matching dark wood finish | |
| Hardware | Zinc-plated steel screws, black plastic mounting brackets, nylon adjustable leveling feet | |
| Edge banding | 1mm thick PVC edge trim with black finish, applied to all desk panel edges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Dual work zones | Two separate user positions split by central privacy divider for adjacent staff seating | |
|---|---|---|
| Integrated storage layout | 2 dedicated vertical CPU bays, 4 open cubby shelves, 1 upper drawer, 1 lower closed cabinet | |
| Cable management | Cutout cable pass-through behind privacy divider for routing monitor and power cables | |
| Leveling adjustment | Adjustable feet on storage base to stabilize desk on uneven office flooring |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office areas | Dual-user layout fits two staff in compact footprint for open workspace plans | |
|---|---|---|
| Small business staff workstations | Integrated storage reduces need for separate cabinets in small offices |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial desks | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated desk cabinetry |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk construction | |
|---|---|---|
| GB/T 4897.3-2018 | Particleboard for furniture use, applicable to engineered board desk panels | |
| GB/T 1931-2009 | Wood furniture moisture content test method, recommended for inbound QC |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk construction; 2. GB/T 4897.3-2018: Particleboard for furniture use, applicable to engineered board desk panels; 3. GB/T 1931-2009: Wood furniture moisture content test method, recommended for inbound QC; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
