Four-Person Cross-Shaped Workstation with Privacy Screens and Integrated Storage (model WS-4P-CROSS-STG-2800) is listed under Open Workstation. Dimensions: 2800 × 2800 × 1200 mm. Materials: Dark wood-grain high-pressure laminate over engineered wood board, with sealed edge banding. Load capacity: 80 kg per station. Product Features: Four-seat,layout,cross-shaped,divider,integrated,storage,power-ready,metal,legs. This page consolidates 5 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | XIANGSHI | Model | WS-4P-CROSS-STG-2800 |
| Overall dimensions (W × D × H) | 2800 × 2800 × 1200 mm | Finished Top Thickness | 50 mm |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | Leg / Support Section | 80 mm main section with 2 mm metal wall |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm | Workstation seating capacity | 4 users |
| Distributed work surface load | 80 kg per station | Central desktop point load | 30 kg |
| Drawer static load | 15 kg | Open shelf static load | 20 kg per shelf |
| Power module outlet count | 4 socket groups | Net weight | 190 kg |
| Recommended floor loading | 2.5 kN/m² | Durability target | 50,000 drawer and door operating cycles |
| Top Static Load Reference | 150 kg uniformly distributed | Work surface | Dark wood-grain high-pressure laminate over engineered wood board, with sealed edge banding |
| Storage cabinet carcass | Matte dark wood-based panel with beige contrasting side panels | Privacy panels | Beige fabric-look padded or wrapped panel on a rigid core |
| Leg frame | Black powder-coated tapered steel legs with metallic gold foot sleeves | Hardware | Black drawer pull, hinges, adjustable glides, and metal connector brackets |
| Cable and power structure | Rear plastic socket inserts with black cable-management rail and under-desk routing space | Four-workstation layout | Cross-shaped plan divides one shared structure into four outward-facing 1400 mm seats, improving space efficiency in open offices. |
| Privacy separation | A continuous central divider and beige end panels create lateral sight barriers without enclosing each seat. | Integrated personal storage | Each visible storage zone combines an open book shelf, lower shelf, drawer, and enclosed or CPU-compatible space. |
| Power and cable routing | Rear socket panels and a horizontal rail allow laptop and monitor cables to route behind the divider instead of crossing walkways. | Carton count | 5 cartons |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
| Reference Packaging Volume | 1 m³/set | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2800 × 2800 × 1200 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Workstation seating capacity | 4 users | |
|---|---|---|
| Distributed work surface load | 80 kg per station | |
| Central desktop point load | 30 kg | |
| Drawer static load | 15 kg | |
| Open shelf static load | 20 kg per shelf | |
| Power module outlet count | 4 socket groups | |
| Net weight | 190 kg | |
| Recommended floor loading | 2.5 kN/m² | |
| Durability target | 50,000 drawer and door operating cycles | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | Dark wood-grain high-pressure laminate over engineered wood board, with sealed edge banding | |
|---|---|---|
| Storage cabinet carcass | Matte dark wood-based panel with beige contrasting side panels | |
| Privacy panels | Beige fabric-look padded or wrapped panel on a rigid core | |
| Leg frame | Black powder-coated tapered steel legs with metallic gold foot sleeves | |
| Hardware | Black drawer pull, hinges, adjustable glides, and metal connector brackets | |
| Cable and power structure | Rear plastic socket inserts with black cable-management rail and under-desk routing space |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Four-workstation layout | Cross-shaped plan divides one shared structure into four outward-facing 1400 mm seats, improving space efficiency in open offices. | |
|---|---|---|
| Privacy separation | A continuous central divider and beige end panels create lateral sight barriers without enclosing each seat. | |
| Integrated personal storage | Each visible storage zone combines an open book shelf, lower shelf, drawer, and enclosed or CPU-compatible space. | |
| Power and cable routing | Rear socket panels and a horizontal rail allow laptop and monitor cables to route behind the divider instead of crossing walkways. |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Carton count | 5 cartons | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
