Automatic mm / inch conversion · Core engineering specifications
| Desktop panel thickness | 25 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 130 kg | |
|---|---|---|
| Desktop static distributed load capacity | 150 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Workstation seating capacity | 2 users | |
| Surface scratch resistance rating | 2000 cycles | |
| Commercial warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | 25mm melamine-faced MDF panel | |
|---|---|---|
| Side cabinet panels | 18mm melamine-faced engineered wood | |
| Edge banding | 2mm thick PVC edge trim | |
| Support legs | 1.5mm thick powder-coated steel | |
| Privacy divider | Fabric-upholstered foam panel | |
| Drawer slides | Cold-rolled steel 3-section full-extension slides | |
| Cabinet hinges | Cold-rolled steel soft-close hinges | |
| Hardware fasteners | Zinc-plated steel screws and cam locks | |
| Adjustable feet | Nylon base with steel threaded stem | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Modular assembly design | Knock-down flat pack construction | |
|---|---|---|
| Storage configuration | Each seat includes 1 lockable drawer, 2 open shelves, 1 fluted door cabinet | |
| CPU storage bay | Open under-desk cubby sized for standard full-size desktop towers | |
| Cable management system | 60mm desk grommets and under-desk cable routing channels | |
| Privacy divider function | 300mm high fabric screen between adjacent seats | |
| Adjustable leveler feet | 15mm vertical adjustment range on all leg bases | |
| Level work surface | Flat continuous worktop per seat with 750mm working height | |
| Lockable storage | Keyed lock on upper personal drawer | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Suits general administration, finance and operational team workspaces | |
|---|---|---|
| Small business startup offices | Fits compact office footprints without separate storage cabinet purchases | |
| Government and institutional workspaces | Meets standard commercial furniture durability requirements for high-traffic use | |
| Project team work zones | Two adjacent seats support collaborative seated work with personal storage | |
| Home office dual-workstation setups | Sized for shared home office spaces for two remote workers | |
| Co-working space dedicated desks | Durable construction supports high turnover of daily users |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables, safety and dimensional requirements for commercial work surfaces | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture, structural stability and strength requirements | |
| EN 1022:2018 | Furniture seating and desk stability testing for domestic and office use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage furniture standard for drawer and shelf load, cycle durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk components | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture laminate finishes | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels used in indoor office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk components; 2. GB/T 4893.4-2013: Surface abrasion resistance test for furniture laminate finishes; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels used in indoor office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
