| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions | 3708 x 3759 x 750 mm | |
|---|---|---|
| Single workstation width | 1800 mm | |
| Single workstation depth | 750 mm | |
| Worktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Seated knee clearance height | 673 mm | |
| Low privacy divider height above worktop | 300 mm | |
| Integrated drawer cabinet height | 550 mm | |
| CPU tower bay opening width | 250 mm | |
| Steel leg wall thickness | 1.5 mm | |
| Cable grommet diameter | 80 mm | |
| Levelling foot adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 517 kg | |
|---|---|---|
| Single worktop static load capacity | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Worktop surface abrasion resistance | 2000 cycles | |
| Seating capacity | 4 users | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop | E1 grade particle board with light oak melamine laminate | |
|---|---|---|
| Frame and legs | Powder-coated off-white steel with angled splayed design | |
| Privacy dividers | MDF core with matte gray laminate surface | |
| Edge banding | 2mm impact-resistant PVC applied to all exposed worktop edges | |
| Storage cabinet bodies | E1 grade MFC (melamine faced chipboard) in off-white finish | |
| Drawer fronts | Matching off-white melamine MDF with integrated key lock | |
| Hardware | Zinc-plated steel connecting brackets, screws and adjustable nylon leveling feet | |
| Cable management grommets | ABS plastic with removable brush insert | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Individual work zones | Four separate dedicated work surfaces separated by low dividers to reduce cross-desk visual distraction | |
|---|---|---|
| Lockable under-desk drawer storage | One lockable drawer per workstation for secure storage of personal office supplies and documents | |
| Dedicated CPU tower bays | Open under-desk bays sized to hold full-size desktop computer towers off the floor | |
| Integrated cable management | Desktop grommets route power and data cords from work surface down to under-desk cable runs | |
| Adjustable floor leveling | Nylon glides at each leg base adjust to correct uneven floors and eliminate desk wobble | |
| Modular connectivity | Cluster frames connect with standard brackets to allow reconfiguration into longer runs | |
| Low privacy screening | Divider panels block direct line of sight to opposite workstations without blocking overhead light | |
| Stable angled leg support | Splayed leg geometry increases footprint width to improve lateral desk stability during use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Configured for 4 staff in collaborative open offices with low visual separation between seats | |
|---|---|---|
| Startup and SME work areas | Cost-effective modular design fits growing teams that require flexible seating layouts | |
| Corporate administrative departments | Durable commercial construction supports daily use for administrative and operational staff | |
| Co-working shared spaces | Individual lockable storage and dedicated work zones suit flexible hot-desking environments | |
| Call center and back-office teams | Low dividers maintain visibility for supervisors while reducing cross-seat distraction | |
| Small branch office fit-outs | All-in-one cluster design reduces installation complexity for small office relocation projects | |
| Training and project team zones | Modular layout can be reconfigured to support short-term project team seating needs |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to worktop and frame performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical safety requirements, applicable to clearance dimensions | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to drawer and cabinet components | |
| EN 13722:2004 | Office furniture strength and durability for storage units, applicable to drawer cycle performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to worktop load and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet durability testing | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emission and indoor air quality verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and cabinet components | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks, applicable to worktop load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to MDF/MFC components | |
| GB/T 24821-2009 | Office furniture panel furniture performance requirements, applicable to cabinet components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and cabinet components; 2. GB/T 3327-2016: Performance test methods for office desks, applicable to worktop load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MDF/MFC components; 4. GB/T 24821-2009: Office furniture panel furniture performance requirements, applicable to cabinet components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
