PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1800 × 1600 × 1350 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed desktop load	80 kg
Cabinet shelf load	25 kg per shelf
Drawer load	15 kg per drawer
Net weight	118 kg
Seating capacity	1 person
Door and drawer cycle rating	50,000 cycles
Leveling adjustment range	10 mm
Warranty period	5 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop and shelves	25 mm wood-grain melamine-faced particleboard with sealed edges
Grey cabinet panels	18 mm warm grey melamine-faced panel with matching edge banding
Hutch side and drawer fronts	18 mm vertical-grain oak-look melamine panels
Support rails	50 x 25 mm rectangular silver powder-coated steel rail
Privacy screen	12 mm white rigid panel with rounded corners
Hardware	Black nylon or zinc-alloy locks, handles and adjustable feet

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Storage configuration	Right-side two-door cabinet, lockable top drawer and lower filing drawer provide enclosed office storage.
Monitor and document riser	Silver metal shelf elevates a monitor or documents 120 mm above the desk while preserving desk depth.
Floor leveling	Four visible adjustable feet align the panel base and cabinet on uneven office floors.
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Private office	Suits one manager or executive because the return adds storage, document space and a separate laptop or reference zone.
Open-plan workstation	Can be used in a focused work bay where the low divider separates the monitor area from neighboring sightlines.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · EWS-L1800-RH-H

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · EWS-L1800-RH-H

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · EWS-L1800-RH-HOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The EWS-L1800-RH-H is an unbranded panel-based L-shaped executive workstation designed for a single user, combining an expansive main desk, a right-hand return, integrated enclosed storage, and an over-desk hutch in one coordinated layout. Its visual character comes from wood-grain melamine work surfaces and hutch panels, warm grey storage panels, silver metal supports, a white privacy screen, and black plastic hardware. The arrangement gives the user a primary work zone, a right-side storage and reference area, and an elevated monitor or document position while maintaining a structured, office-ready appearance. The desktop and shelves use 25 mm wood-grain melamine-faced particleboard with sealed edges, while the grey cabinet panels use 18 mm warm grey melamine-faced panel with matching edge banding. Hutch sides and drawer fronts are finished in 18 mm vertical-grain oak-look melamine. The silver support system includes powder-coated steel rails, with an 80 mm main support section and 2 mm metal wall; the finished top thickness is 50 mm. Black nylon or zinc-alloy locks, handles, and adjustable feet complete the specification. The 12 mm white rigid privacy screen has rounded corners and helps separate the monitor area from adjacent sightlines. Functionally, the right return houses a two-door cabinet, a lockable top drawer, and a lower filing drawer. The hutch includes a silver metal shelf that raises a monitor or documents 120 mm above the desk and preserves usable desk depth. Cable management is integrated through an 80 mm cable opening and a tray with 120 mm depth, providing a reference capacity for 10 power or data cables and a tray load capacity of 10 kg. Four visible adjustable feet offer 10 mm of leveling adjustment for uneven floors. Rated storage capacity is 80 kg distributed across the desktop, 25 kg per cabinet shelf, and 15 kg per drawer; door and drawer hardware is rated for 50,000 cycles. Each main seat position provides 680 mm high and 900 mm wide knee clearance. This workstation is well suited to a private manager or executive office, where the return supports storage, documents, and a separate laptop or reference zone. It can also be placed in a focused open-plan work bay, where the low divider helps define the user’s visual space. Procurement teams should plan for a one-person desk with a net weight of 118 kg and allow time for on-site assembly, referenced at 40 minutes per set. Packaging information should be confirmed at order stage because the supplied records include both a two-carton set reference and a four-carton gross-weight reference. Delivery access, floor protection, leveling, and cable layout should be checked before installation.

Panel-Based L-Shaped Executive Workstation with Right Return Storage and Over-Desk Hutch Specifications
