Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (with hutch) | 1830 x 1830 x 1665 mm | |
|---|---|---|
| Desktop work surface height | 760 mm | |
| Desktop panel thickness | 25 mm | |
| Main desktop depth | 700 mm | |
| Return desktop depth | 600 mm | |
| Knee clearance height under desk | 650 mm | |
| Knee clearance width (open CPU bay) | 600 mm | |
| Modesty panel thickness | 19 mm | |
| Upper open cube shelf internal dimensions | 350 x 350 x 300 mm | |
| Upper closed cabinet internal shelf depth | 350 mm | |
| Lower cabinet door height | 700 mm | |
| Cable grommet diameter | 60 mm | |
| Edge banding thickness | 2 mm | |
| Base foot cutout height | 20 mm | |
| Middle open display shelf height | 350 mm | |
| Finished Top Thickness | 50 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Locking cabinet secure storage load | 25 kg | |
| Drawer/cabinet hinge cycle rating | 50000 open/close cycles | |
| Recommended maximum user weight for seated use | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Net product weight | 113 kg | |
| Manufacturer warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desk top core material | 18mm thick particle board core with 25mm total finished thickness | |
|---|---|---|
| Desk and hutch surface finish | Thermally fused light gray matte laminate | |
| Edge protection | 2mm thick impact-resistant PVC edge banding | |
| Cabinet door construction | 19mm thick engineered wood panels with flush flat design | |
| Lock mechanism | Combination digital lock with metal strike plate | |
| Structural support panels | 19mm thick engineered wood end panels and dividers | |
| Cable grommets | ABS plastic black finish grommets with removable caps | |
| Base feet | Integral engineered wood feet with small floor cutouts | |
| Modesty panel | 19mm thick engineered wood full-height front panel | |
| Hinge hardware | Cold-rolled steel concealed hinges | |
| Shelf material | 19mm thick engineered wood fixed shelves | |
| Wall anchor hardware | Included steel anti-tip bracket and fasteners |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Two 60mm desktop grommets route cables from work surface to under-desk area | |
|---|---|---|
| Upper hutch storage configuration | Two closed flat-panel cabinet doors plus four open cube shelves | |
| Lower storage configuration | Two closed cabinet doors (one combination-locked) plus open CPU bay | |
| Middle open display shelf | Full-width open shelf spanning hutch between upper and lower storage | |
| Secured storage function | Combination lock on lower cabinet restricts access to confidential documents | |
| CPU compartment accommodation | Open under-desk bay fits full-size ATX computer towers up to 550mm tall | |
| Work surface configuration | L-shaped corner layout provides two connected work zones for multitasking | |
| Anti-tip safety function | Included wall anchor secures tall hutch to wall to prevent forward tip-over | |
| Floor leveling function | Integral base cutouts accommodate minor floor unevenness for stable placement | |
| Storage organization function | Fixed shelf dividers create separated compartments for sorted document and supply storage | |
| Work surface privacy function | Full-height front modesty panel blocks view of under-desk area from seated front position | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office use | Suitable for manager or executive offices with integrated storage for files and supplies | |
|---|---|---|
| Home office workspace | Ideal for dedicated home offices requiring both work area and display/locked storage | |
| Small business workstation | Appropriate for startup or small office spaces that need combined work and storage in one unit | |
| Corner room installation | Designed to fit 90-degree room corners to utilize otherwise wasted floor space | |
| Multi-device work setup | Supports desktop computer, laptop, monitor and peripherals with dedicated cable management | |
| Mixed storage and display use | Balances open shelves for decor, closed cabinets for supplies, and locked storage for sensitive items | |
| Light commercial office use | Suitable for light daily office use with durable laminate surface and rated load capacities |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for desk load and stability | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for hutch cabinet performance | |
| EN 13722:2004 | Furniture test methods for strength and durability of storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for static load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable for hutch and cabinet load and cycle performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desk structural safety and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particle board for furniture use, applicable for core material performance requirements | |
| GB 28007-2011 | Safety requirements for children's and adult office furniture, applicable for tip-over resistance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk structural safety and finish quality; 2. GB/T 4897.3-2003: Particle board for furniture use, applicable for core material performance requirements; 3. GB 28007-2011: Safety requirements for children's and adult office furniture, applicable for tip-over resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
