Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (worktop height) | 2400 x 600 x 750 mm | |
|---|---|---|
| Overall height including privacy dividers | 1120 mm | |
| Worktop panel thickness | 32 mm | |
| PVC edge banding thickness | 1 mm | |
| Central storage pedestal dimensions | 410 x 430 x 660 mm | |
| Desktop privacy divider dimensions (per seat) | 800 x 320 x 16 mm | |
| Steel leg wall thickness | 1.024 mm | |
| Seated knee clearance height under worktop | 690 mm | |
| Knee clearance width per user position | 980 mm | |
| Drawer internal dimensions (per drawer) | 350 x 380 x 150 mm | |
| Open shelf compartment height | 200 mm | |
| Angled leg base footprint | 60 mm diameter contact point | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 100 kg | |
|---|---|---|
| Worktop distributed static load capacity | 120 kg | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Worktop surface abrasion resistance | 2000 revolutions | |
| Powder-coated steel frame rust resistance | 48 hours salt spray exposure | |
| Recommended maximum user weight per position | 110 kg | |
| Product structural warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 32mm thick melamine-faced MFC (particleboard) core | |
|---|---|---|
| Edge banding | 1mm thick PVC edging applied to all exposed panel edges | |
| Support legs | 1.024mm wall thickness powder-coated white steel, tapered angled form | |
| Central storage pedestal carcass | 16mm thick melamine-faced MFC panel, white finish | |
| Drawer fronts | 16mm thick melamine-faced MFC panel, sage green finish | |
| Desktop privacy dividers | 16mm thick MFC core with matte sage green laminate finish | |
| Drawer slides | Cold-rolled steel 3-section full-extension smooth-glide slides | |
| Leveling feet | Injection-molded nylon adjustable feet at pedestal base | |
| Surface finish coating | Scratch-resistant, water-resistant melamine laminate on work surfaces | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Fixed central shared pedestal with 2 soft-close drawers and 2 open storage shelves | |
|---|---|---|
| Privacy separation | Two upright desktop dividers mounted between work zones to block lateral sightlines | |
| Seated access | Open knee clearance bays on both sides of central pedestal for unobstructed chair access | |
| Floor leveling | Adjustable nylon feet on pedestal base to compensate for uneven carpeted or hard floors | |
| Cable management | Integrated rear cable routing channel behind central pedestal to route power and data cords | |
| Assembly type | Knock-down (CKD) flat-pack construction with cam-lock and screw hardware | |
| Drawer operation | Full-extension smooth-glide drawers with integrated recessed handles for easy document access | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff work areas | Provides two dedicated work positions with privacy separation for daily administrative work | |
|---|---|---|
| Small startup team workspaces | Compact shared footprint reduces layout waste while offering integrated storage for two users | |
| Home office dual-work setups | Scaled design works in large home studies for two people working from home | |
| Freelancer co-working spaces | Modular design allows adjacent placement to create larger workstation banks for flexible seating | |
| Recommended pairing | Matches with mesh-back office task chairs with adjustable height and rolling casters | |
| Layout note | Position against room dividers or windows with 1000mm clearance behind each seat for chair movement |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable to work height and clearance dimensions | |
|---|---|---|
| EN 527-2:2002 | Office work tables - Part 2: Mechanical safety requirements, applicable for structural stability testing | |
| EN 14073-2:2004 | Office furniture - Storage units - Part 2: Safety requirements, applicable to drawer pedestal |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for performance and durability, applicable for load and cycle testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood-composite desk components | |
|---|---|---|
| GB/T 3327-2016 | Test methods for strength and durability of desks and tables, applicable for structural load testing | |
| GB 18584-2001 | Limit of formaldehyde emission for interior decoration wooden furniture, applicable for panel material testing | |
| GB/T 19995.1-2005 | Performance requirements for office work surfaces, applicable to worktop wear and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood-composite desk components; 2. GB/T 3327-2016: Test methods for strength and durability of desks and tables, applicable for structural load testing; 3. GB 18584-2001: Limit of formaldehyde emission for interior decoration wooden furniture, applicable for panel material testing; 4. GB/T 19995.1-2005: Performance requirements for office work surfaces, applicable to worktop wear and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
