Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1200 x 750 mm | |
|---|---|---|
| Per-seat workstation width | 1400 mm | |
| Work surface depth per user | 600 mm | |
| Under-desk seated knee clearance height | 650 mm | |
| Knee clearance depth per user | 450 mm | |
| Work surface thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel leg tube wall thickness | 1.2 mm | |
| Privacy divider height above work surface | 300 mm | |
| Central storage unit height | 600 mm | |
| Drawer internal dimensions | 400 x 350 x 120 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 180 kg | |
|---|---|---|
| Work surface static uniform load capacity | 120 kg per seat | |
| Drawer slide rated load per drawer | 25 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Cabinet hinge cycle rating | 80000 open/close cycles | |
| Recommended number of users | 4 people | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface top | 25mm thick MFC core with beige woodgrain melamine laminate | |
|---|---|---|
| Edge banding | 2mm thick PVC edge trim with rounded profile | |
| Support legs | 1.2mm thick chrome-plated angled steel tube | |
| Central storage cabinet panels | 18mm thick MDF with white and beige woodgrain laminate | |
| Desktop privacy dividers | 8mm thick frosted acrylic with silver aluminum frame | |
| Drawer fronts | White laminated MDF with integrated recessed pull handles | |
| Open storage cubby interiors | Black matte laminated MDF | |
| Leveling feet | Nylon base adjustable glides | |
| Hardware fasteners | Zinc-plated steel bolts and cam locks | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 4 individual face-to-face work positions with dedicated knee clearance | |
|---|---|---|
| Privacy screening | Two desktop-mounted frosted dividers separate opposite-facing users | |
| Central storage layout | Integrated unit includes lockable small drawers, open cubbies, and hinged cabinet doors | |
| Cable management | Desktop cable grommets and under-desk routing channels route power/data cables | |
| Adjustable leveling | Bottom-mounted glides adjust up to 10mm to stabilize desk on uneven floors | |
| Drawer operation | Smooth-glide side-mounted drawer slides allow full extension for access | |
| Cabinet door access | Hinged doors open 110 degrees for stored item access without blocking knee space | |
| Open cubby storage | Three open shelves per side for frequently accessed items and printer paper | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Provides 4 dedicated workstations with visual separation for team departments | |
|---|---|---|
| Small business shared office spaces | Compact footprint accommodates four staff without separate cubicle partitions | |
| Startup team work zones | Integrated storage reduces need for separate filing cabinets in tight spaces | |
| Corporate administrative departments | Matching neutral finishes coordinate with standard mesh task chairs and office decor | |
| Co-working space dedicated desk zones | Durable commercial construction supports daily use by rotating members | |
| Sales and operations team floors | Face-to-face layout supports quick collaboration between adjacent team members |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables: Dimensions, safety requirements and test methods for work surfaces | |
|---|---|---|
| EN 527-2:2016 | Office work tables: Mechanical safety requirements for structural stability and load | |
| EN 1335-1:2020 | Office work chair dimensions, referenced for matched seat/desk clearance compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products: Performance and safety standard for commercial office work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units: Performance standard for integrated under-desk cabinet and drawer components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminated panel storage components | |
|---|---|---|
| GB/T 3323-2017 | Metal furniture general technical requirements, applicable to steel leg and frame components | |
| GB/T 35607-2017 | Green product assessment standard for furniture, applicable for low-VOC material procurement | |
| GB 28007-2011 | Furniture mechanical safety performance requirement, covers edge rounding and stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminated panel storage components; 2. GB/T 3323-2017: Metal furniture general technical requirements, applicable to steel leg and frame components; 3. GB/T 35607-2017: Green product assessment standard for furniture, applicable for low-VOC material procurement; 4. GB 28007-2011: Furniture mechanical safety performance requirement, covers edge rounding and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
