| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2000 x 1600 x 1250 mm | |
|---|---|---|
| Main work surface height | 750 mm | |
| Main work surface top panel thickness | 25 mm | |
| Main work surface width (leg-supported section) | 1600 mm | |
| Main work surface depth | 800 mm | |
| Right storage return width | 1200 mm | |
| Right storage return depth | 400 mm | |
| Seated knee clearance height under main desk | 720 mm | |
| Raised desktop organizer shelf height above work surface | 300 mm | |
| Desktop metal grid divider height above work surface | 250 mm | |
| File drawer front height | 300 mm | |
| Open storage cubby internal depth | 380 mm | |
| Edge band thickness on all wood panels | 2 mm | |
| Cable grommet diameter on work surface | 80 mm | |
| Hairpin leg tube diameter | 12 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 82 kg | |
|---|---|---|
| Main work surface static load capacity | 150 kg | |
| Leveler foot adjustment range | 10 mm | |
| Drawer slide rated cycle life | 50000 cycles | |
| Surface laminate abrasion resistance | 2000 cycles | |
| Recommended seated user capacity | 2 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and storage panels | E0-grade engineered particleboard with weathered light washed wood laminate | |
|---|---|---|
| Frame, legs and divider | 1.2mm thick steel with matte black powder-coated finish | |
| Drawer fronts | Matte dark gray thermofoil laminate over engineered wood | |
| Drawer slides | Cold-rolled steel full-extension ball bearing slides | |
| Leveler feet | Nylon-padded adjustable steel feet | |
| Edge banding | 2mm thick PVC edge banding matching wood finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | 60mm recessed cable pass-through on main work surface routes cords to under-desk space | |
|---|---|---|
| File storage | Two lockable dark gray drawers accommodate hanging letter/legal size files | |
| Open storage | Four divided open cubbies in return base and two raised organizer shelves for quick-access supplies | |
| Desktop divider | Diamond-pattern black metal grid screen provides low visual privacy between work zones |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office and small private executive office | Provides dedicated work surface and integrated storage for individual use | |
|---|---|---|
| Open-plan office workstation | Low divider adds partial privacy without blocking sight lines |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for commercial office use | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic and office seating-adjacent tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, recommended for commercial-grade load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural integrity | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks, applicable for work surface and drawer durability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for E0-grade substrate compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural integrity; 2. GB/T 3327-2016: Performance requirements for office desks, applicable for work surface and drawer durability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for E0-grade substrate compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
