PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended users	2 seated workers
Distributed top static load	100 kg total
Single-position equipment load	50 kg
Central pedestal top load	30 kg
Drawer load per drawer	15 kg
Open shelf load	20 kg
Workstation net weight range	128 kg
Floor contact points	8 metal legs plus cabinet base pads
Design service life target	8 years
Footprint per occupant	1400 x 1200 mm

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25 mm melamine-faced particleboard or MDF core with walnut wood-grain finish and sealed edges
Edge banding	2 mm PVC edge banding on exposed desktop and panel edges
Central cabinet carcass	18 mm melamine-faced wood-based panel with walnut vertical sides and gray drawer fronts
Drawer box	12 mm laminated drawer sides with metal ball-bearing slides
Divider screens	30 mm padded fabric-covered panel over wood or composite frame
Support legs	32 mm powder-coated steel round tubes with angled A-frame geometry

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Central storage	Two gray drawer fronts provide personal or shared storage, with the upper front configured for a single lock position
Workstation division	Two upholstered divider screens separate adjacent work zones and reduce direct visual distraction while seated
Under-desk equipment bay	Open shelf beside the central pedestal accepts a computer tower or compact printer with front access
Floor support system	Outer angled metal legs carry the cantilevered bench tops, while the central cabinet forms a load-bearing spine

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office	Suitable for two-person team neighborhoods where central storage and low divider screens balance interaction and privacy
Project-based workstation area	Recommended for procurement fit-outs needing repeatable back-to-back benches with CPU storage and compact footprints

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-2P-CAB-SCREEN-2800

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-2P-CAB-SCREEN-2800

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-2P-CAB-SCREEN-2800Open Export Tool

Quick Actions

Post an RFQ

Product Description

This two-person shared office workstation presents a structured back-to-back bench layout designed to balance collaboration and seated privacy. Two work surfaces are arranged around a central storage spine, while upholstered divider screens separate the adjacent work zones and reduce direct visual distraction. Its walnut wood-grain finish, gray drawer fronts, and angled gray metal supports give the system a coordinated commercial appearance suited to organized open-plan environments. The desk tops use 25 mm melamine-faced particleboard or MDF core panels with a walnut wood-grain appearance and sealed edges. Exposed desktop and panel edges are protected by 2 mm PVC edge banding. Support is provided by powder-coated steel round tubes formed into angled A-frame legs, which carry the cantilevered bench tops. The central cabinet also acts as a load-bearing spine, creating a stable framework for the double-sided layout. The divider screens consist of padded, fabric-covered panels over a wood or composite frame, adding a softer visual boundary between users. Central storage is integrated directly into the workstation. Two gray drawer fronts offer personal or shared storage, with the upper front configured for a single lock position. Drawer boxes use laminated sides and metal ball-bearing slides for regular office access. Beside the pedestal, an open under-desk shelf provides front access for a computer tower or compact printer, helping keep the work surface clear. Each main seat position includes an 80 mm cable opening, and the cable tray offers routing space beneath the top for power and data leads. The workstation is intended for two seated workers and is well suited to open-plan team neighborhoods, project-based work areas, and fit-out programs requiring repeatable benches with compact footprints. Its central storage, CPU bay, and low screens make it appropriate where users need to interact without losing individual focus. It can also serve residential work studios or home office environments that require two defined work positions in one coordinated system. Procurement teams should review load requirements alongside intended equipment. The rated distributed top load is 100 kg total, with a 50 kg limit for equipment in a single position. The central pedestal top supports 30 kg, each drawer supports 15 kg, and the open shelf supports 20 kg. Planning should also account for the finished 50 mm top thickness, 680 mm high and 900 mm wide knee clearance per main seat, and the need for cable management access. The product is supplied as an unbranded office workstation and should be ordered with delivery, handling, and assembly coordination in mind.

Two-Person Shared Office Workstation with Central Storage and Desk Screens Specifications
