| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 1600 x 1400 x 750 mm | |
|---|---|---|
| Per-user work surface dimensions | 1600 x 600 mm | |
| Under-desk seated knee clearance height | 673 mm | |
| Central desktop privacy divider dimensions | 1200 x 350 x 25 mm | |
| Raised rear cable shelf/raceway dimensions | 1400 x 200 x 100 mm | |
| Integrated side storage pedestal dimensions | 400 x 550 x 700 mm | |
| Worktop panel thickness | 25 mm | |
| Steel support leg profile | 44 x 44 mm square tube | |
| Steel leg wall thickness | 1.5 mm | |
| PVC edge banding thickness | 2 mm | |
| Work surface cable grommet diameter | 60 mm | |
| Pedestal drawer internal clear height | 250 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total workstation net weight | 154 kg | |
|---|---|---|
| Single work surface static center load capacity | 140 kg | |
| Drawer slide operational cycle rating | 50000 open/close cycles | |
| Pedestal lock keyed differ cycle rating | 10000 lock/unlock cycles | |
| Recommended user capacity | 2 seated office workers | |
| Surface wear resistance rating | 2000 abrasion cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | E1 grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Support legs | Powder-coated square steel tube with color-matched end caps | |
| Central privacy divider | Medium density fiberboard with terracotta matte laminate finish, clear acrylic mounting clips | |
| Rear raised raceway frame | Powder-coated light gray steel frame with white laminate shelf surface | |
| Side storage pedestal body | Melamine-faced particleboard panels with white and light gray matte finish, central keyed cam lock | |
| Pedestal drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Cable management components | ABS plastic grommets and under-desk cable tray | |
| Foot glides | Nylon adjustable leveling glides at all leg and pedestal base points | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Privacy screen function | Fixed central divider blocks direct line of sight between facing seated users, reduces visual distraction | |
|---|---|---|
| Storage pedestal function | Integrated lockable two-drawer cabinet secures personal items and hanging office files, supports end of worktop | |
| Cable management function | Recessed worktop grommet routes power and data cables to under-desk raceway, raised rear shelf holds power strips off work surface | |
| Leveling function | Adjustable nylon glides at all base contact points compensate for uneven office flooring, prevents desk wobble | |
| Modular expansion function | Pre-drilled connection points allow linking additional matching workstations to form larger open-plan clusters | |
| Work surface function | Scratch and stain resistant melamine surface supports daily office tasks including computer work, writing and document placement | |
| Drawer access function | Full-extension ball-bearing slides allow full access to rear of drawers without binding during daily use | |
| Edge protection function | Thick PVC edge banding on all worktop edges resists impact damage from regular contact and office equipment placement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff zones | Suitable for two employees per unit, reduces cross-user distraction with central privacy screen | |
|---|---|---|
| Call center and customer service floors | Compact footprint fits dense seating layouts, integrated storage eliminates need for separate cabinets | |
| Startup and coworking spaces | Modular design supports flexible reconfiguration as team size and layout changes | |
| Small business administrative areas | All-in-one desk and storage unit reduces separate furniture procurement and installation costs | |
| Government and corporate back-office work areas | Neutral professional color scheme matches standardized office interior design palettes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applies to worktop load and structural stability | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and ergonomic requirements, applies to knee clearance and work surface height | |
| EN 15372:2016 | Office furniture storage units safety, strength and durability requirements, applies to integrated pedestal | |
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion, applies to melamine finish performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applies to static load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applies to integrated lockable pedestal load and cycle testing | |
| ANSI/BIFMA X5.11-2015 | Large occupancy office products test methods, applies to multi-user workstation stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to panel desk structural performance and finish quality | |
|---|---|---|
| GB/T 3327-2021 | Performance test methods for office desks and chairs, applies to worktop load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applies to E1 grade panel material selection | |
| GB/T 24821-2009 | Office furniture storage cabinet performance requirements, applies to integrated pedestal durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to panel desk structural performance and finish quality; 2. GB/T 3327-2021: Performance test methods for office desks and chairs, applies to worktop load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applies to E1 grade panel material selection; 4. GB/T 24821-2009: Office furniture storage cabinet performance requirements, applies to integrated pedestal durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
