Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1600 x 750 mm | |
|---|---|---|
| Per-position worksurface size | 1200 x 800 mm | |
| Desktop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Under-desk knee clearance height | 725 mm | |
| Knee clearance depth per position | 600 mm | |
| Privacy divider height above desktop | 300 mm | |
| Privacy divider thickness | 25 mm | |
| Cantilever end leg wall thickness | 1.5 mm | |
| Storage pedestal external dimensions | 400 x 600 x 650 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worksurface static load capacity | 135 kg | |
|---|---|---|
| Storage drawer slide load rating | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Lock mechanism cycle rating | 10000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Unit net weight | 260 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Leveling foot adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface core | E1 grade particleboard | |
|---|---|---|
| Worksurface finish | Thermally fused white melamine laminate | |
| Edge banding | 2mm thick ABS edging | |
| Support frame | 1.5mm thick powder-coated white steel | |
| Privacy divider core | High-density fiberboard | |
| Privacy divider upholstery | Grey polyester acoustic fabric | |
| Storage pedestal body | 0.8mm thick powder-coated white steel | |
| Drawer hardware | Cold-rolled steel ball-bearing slides | |
| Cable grommets | ABS plastic recessed ports | |
| Leveling feet | Nylon base with steel threaded stem | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Recessed desktop grommets with under-desk steel cable trays | |
|---|---|---|
| Lockable storage pedestals | 2-drawer lockable pedestals per opposing work position | |
| Privacy screening | Two desktop-mounted fabric dividers between opposite seating rows | |
| Modular frame design | Conjoinable steel frame system | |
| Floor leveling | Adjustable nylon feet on all legs and pedestals | |
| Worksurface configuration | Back-to-back dual-row seating for 4 total users | |
| Cable grommet operation | Soft-brush sealed ports | |
| Pedestal mobility | Low-profile caster wheels on pedestal bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff zones | 4-person clustered seating for department teams | |
|---|---|---|
| Call center and shared workspaces | High-density seating for rotating or permanent staff | |
| Startup and co-working environments | Modular white finish matches modern office aesthetics | |
| Administrative and back-office areas | Dedicated work positions with built-in file storage | |
| Recommended accessory pairing | Matching ergonomic task chairs, under-desk CPU holders, monitor arms |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables - Safety and strength requirements | |
|---|---|---|
| EN 1335-1:2000 | Office furniture - Office work chair dimensions | |
| EN 1022:2019 | Furniture - Seating and tables - Determination of stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for safety, durability, structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Tests for safety and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 5237.4-2017 | Wrought aluminum alloy profiles for architecture | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 5237.4-2017: Wrought aluminum alloy profiles for architecture; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
