Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1400 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Front desktop divider height | 300 mm | |
| Rear partition panel height | 700 mm | |
| Per-user work surface width | 1200 mm | |
| Per-user work surface depth | 600 mm | |
| Under-desk knee clearance height | 650 mm | |
| Side storage pedestal width | 400 mm | |
| Drawer internal height | 150 mm | |
| Metal leg diameter | 50 mm | |
| Panel thickness (worktop/partitions) | 25 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop uniform distributed load capacity | 100 kg | |
|---|---|---|
| Recommended maximum user weight per seat | 110 kg | |
| Surface scratch resistance rating | 2000 cycles | |
| Product net weight (reference) | 85 kg | |
| Structural warranty period | 5 years | |
| Available finish color options | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm E1-grade melamine laminated particle board | |
|---|---|---|
| Rear modesty/privacy panel | 25mm dark grey melamine laminated engineered wood | |
| Side cabinet outer panels | 25mm dark grey melamine laminated engineered wood | |
| Drawer fronts | 18mm light wood-effect melamine laminated engineered wood | |
| Support legs | 50mm diameter powder-coated black steel splayed legs | |
| Front desktop divider | 18mm rigid grey matte composite panel | |
| Edge sealing | 2mm thick impact-resistant PVC edge banding | |
| Drawer hardware | Cold-rolled steel side-mount drawer slides | |
| Leveling feet | Polymer-tipped adjustable steel glides | |
| Wire management grommets | ABS plastic desk cable ports | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dual side-by-side work positions | Two separate dedicated work zones separated by a front low divider | |
|---|---|---|
| Fixed integrated side storage return | Right-side cabinet with 2 drawers and 1 open intermediate shelf | |
| Splayed steel leg support | Two outward-angled front legs provide stable lateral support for overhanging worktop | |
| Integrated privacy screening | Tall rear panel blocks cross-aisle visibility at seated eye level | |
| Cable management routing | Dedicated desktop grommets route power/data cables below the work surface | |
| Adjustable floor leveling | Threaded foot pads compensate for uneven office flooring to eliminate wobble | |
| Knock-down modular assembly | Flat-packed components allow on-site assembly with standard hardware | |
| Drawer pull-out access | Full 3/4 extension slides allow easy access to stored office documents and supplies | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Provides partitioned individual work zones for two employees with shared side storage, reducing visual distraction | |
|---|---|---|
| Small business startup workspaces | Compact dual-station design fits standard 3m office bay sizes for efficient space utilization | |
| Corporate department work floors | Modular design allows linking with additional matching workstations to create larger cluster layouts | |
| Satellite office and branch locations | Flat-packed construction reduces shipping costs for multi-location office fit-out projects | |
| Government and institutional office spaces | Neutral two-tone commercial finish meets formal office aesthetic requirements for public sector workspaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for structural load verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and ergonomic requirements, applicable for clearance validation | |
| EN 13722:2004 | Furniture strength and durability requirements for office storage pedestals, applicable for drawer testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable for worktop load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for integrated pedestal drawer load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and finish quality checks | |
|---|---|---|
| GB/T 3327-2016 | Performance and dimension standards for office desks and workstations, applicable for ergonomic and structural verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1-grade panel material acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture coatings, applicable for melamine finish durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel construction and finish quality checks; 2. GB/T 3327-2016: Performance and dimension standards for office desks and workstations, applicable for ergonomic and structural verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1-grade panel material acceptance; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture coatings, applicable for melamine finish durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
