Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1400 x 1100 mm | |
|---|---|---|
| Per-user worksurface size | 1400 x 600 mm | |
| Worksurface height | 750 mm | |
| Privacy divider height above worksurface | 350 mm | |
| Knee clearance height under worksurface | 620 mm | |
| Knee clearance width per position | 600 mm | |
| CPU storage compartment dimensions | 250 x 500 x 450 mm | |
| Worksurface panel thickness | 25 mm | |
| PVC edge banding thickness | 2.0 mm | |
| Support beam cross section | 50 x 25 mm | |
| Splayed leg tube wall thickness | 1.5 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worksurface static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Pedestal lock cycle rating | 10000 cycles | |
| Net weight per workstation set | 210 kg | |
| Recommended user weight per seat | 130 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period for commercial use | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface panel | 25mm E1 grade melamine-faced chipboard, light oak wood grain finish, 2mm PVC edge banding | |
|---|---|---|
| Outer support legs | 1.5mm thick powder-coated matte off-white steel, angled splayed design | |
| Structural support beams | 1.2mm thick rectangular powder-coated steel frame, connecting leg and pedestal assemblies | |
| Privacy dividers | 30mm thick upholstered medium-grey fabric over MDF core, rounded top edges | |
| Integrated storage pedestals | 18mm thick matte off-white melamine MFC, 1 drawer + 1 file cabinet configuration with key lock | |
| CPU compartment panels | 18mm thick matte off-white melamine MFC, open slotted design for ventilation | |
| Hardware fasteners | Zinc-plated steel screw and cam lock assembly for knock-down construction | |
| Leveling feet | 10mm diameter adjustable nylon feet at pedestal bases, 15mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Per-user keyed storage lock | Single key lock secures top drawer and lower file compartment for personal items | |
|---|---|---|
| Under-desk CPU storage | Open dedicated compartment adjacent to each pedestal holds standard mid-tower PCs | |
| Privacy divider separation | 350mm high fabric panels block direct line of sight between opposite seated users | |
| Cable management grommets | 60mm diameter plastic grommets at each work position route power and data cables below surface | |
| Modular expandability | Bench-style frame supports addition of matching 2-person extensions to expand seat count | |
| Floor leveling adjustment | Adjustable nylon feet on pedestal and leg bases compensate for uneven office floors | |
| File storage configuration | Lower pedestal compartment accommodates A4 and foolscap hanging file folders | |
| Surface stain resistance | Melamine laminate resists common office liquid spills and stains for easy cleaning | |
| Locking drawer pedestal dimensions | 400 x 550 x 600 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Provides dedicated individual workspaces with visual privacy for teams of 4 | |
|---|---|---|
| Startup and co-working spaces | Modular design supports flexible seating arrangement and easy reconfiguration | |
| Administrative department offices | Integrated storage keeps documents and personal items organized per user | |
| Corporate back-office work zones | Durable commercial construction withstands high daily use in busy office environments | |
| Call center and operational workspaces | Compact per-seat layout maximizes floor space efficiency while maintaining ergonomic clearance | |
| Small business open workspaces | All-in-one desk and storage design reduces separate furniture procurement needs |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial desks | |
|---|---|---|
| EN 527-2:2019 | Office work tables, dimensional and ergonomic clearance requirements | |
| EN 13722:2004 | Office furniture, storage units strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to pedestal drawer slide and lock performance | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and recycled content |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk construction quality | |
|---|---|---|
| GB/T 3327-2022 | Office desks and tables, applicable to dimensional and strength performance requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use | |
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk construction quality; 2. GB/T 3327-2022: Office desks and tables, applicable to dimensional and strength performance requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use; 4. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
