Single-Person Open-Plan Staff Office Workstation Desk with Attached Storage and Privacy Screen (model WS-SGL-1850-ASY-ORG) is listed under Open Workstation, with overall dimensions of 1850 × 750 × 1200 mm and main material of Particle‑board (PB). Load capacity: 136 kg. Certifications: modular,workstation,integrated,storage,desk-mounted,privacy,screen,splayed,metal,legs,power,module. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 1850 x 750 x 1200 mm | |
|---|---|---|
| Main desktop working height | 750 mm | |
| Main desktop working surface depth | 600 mm | |
| Seated knee clearance height under desktop | 650 mm | |
| Right-side fixed storage pedestal width | 450 mm | |
| Elevated rear shelf height above main desktop | 350 mm | |
| Privacy screen panel dimensions | 1100 x 41 x 300 mm | |
| Desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Upper storage drawer internal height | 150 mm | |
| Lower cabinet door internal height | 500 mm | |
| Cable grommet diameter | 60 mm | |
| Angled steel leg section size | 50 x 50 mm | |
| Leveling foot base diameter | 50 mm | |
| Orange front accent panel dimensions | 300 x 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 136 kg | |
|---|---|---|
| Single drawer slide load rating | 25 kg | |
| Product net weight | 80 kg | |
| Suggested user weight capacity | 113 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop and storage panels | 25mm melamine-faced particle board with 2mm PVC edge banding | |
|---|---|---|
| Support frame and legs | Powder-coated matte black steel with splayed angled profile | |
| Privacy screen | Dark green polyester fabric over MDF core with black metal frame | |
| Drawer and cabinet hardware | Zinc-plated steel ball-bearing slides, recessed orange thermoplastic pulls | |
| Rear shelf structure | 18mm melamine-faced engineered wood with black edge trim | |
| Leveling components | Nylon base adjustable feet with steel threaded stems |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Integrated 60mm grommet and under-desk cable routing channel | |
|---|---|---|
| Lockable storage option | Keyed lock compatible with top drawers for secure document storage | |
| Leveling adjustment | 15mm vertical adjustment range on all support feet | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff work zones | Individual workstation for daily computer, paperwork, and communication tasks | |
|---|---|---|
| Small business and startup offices | Compact all-in-one desk with integrated storage to reduce separate furniture purchases |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 15372:2016 | Office furniture storage units safety requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables | |
| GB 20286-2006 | Fire safety requirements for public place furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 10357.1-2013: Furniture mechanical performance test for tables; 3. GB 20286-2006: Fire safety requirements for public place furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
