| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (including screen and pedestal) | 1500 x 1200 x 1120 mm | |
|---|---|---|
| Standard work surface height | 750 mm | |
| Individual work zone size per user | 1200 x 600 mm | |
| Central privacy divider dimensions | 1200 x 350 x 32 mm | |
| Integrated 4-drawer pedestal dimensions | 600 x 450 x 600 mm | |
| Seated knee clearance under worktop | 620 mm high x 500 mm deep per user | |
| Worktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel leg section dimension | 50 x 50 mm square tubing | |
| Steel frame wall thickness | 1.5 mm | |
| Cable grommet opening diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total worktop static load capacity | 300 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 open/close cycles | |
| Lock mechanism cycle rating | 10000 lock/unlock cycles | |
| Surface abrasion resistance | 2000 revolutions | |
| Product net weight reference | 60 kg | |
| Recommended user count | 2 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | 25mm melamine-faced engineered wood | |
|---|---|---|
| Support frame and legs | 1.5mm powder-coated square steel tubing | |
| Central privacy divider | 32mm fiberboard core with reddish-brown laminate/ fabric facing | |
| Drawer front panels | 18mm melamine-faced engineered wood | |
| Drawer sides and internals | 12mm particleboard with galvanized steel slide hardware | |
| Locking hardware | Zinc alloy keyed cam locks | |
| Pedestal support legs | Tapered powder-coated steel legs | |
| Cable management components | ABS plastic grommets and steel cable tray | |
| Edge banding | 2mm PVC edge trim | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Split by central divider to provide separate 600mm deep work areas for two users | |
|---|---|---|
| Integrated fixed storage pedestal | 4 stacked drawers positioned on one side for shared or primary user storage | |
| Locking drawer security | 2 key-locked drawers to secure confidential documents and personal items | |
| Central cable management | Recessed grommet and under-desk cable tray route power and data cables away from work surfaces | |
| Stable cantilever leg support | Open-frame leg design eliminates cross-braces to maximize knee clearance for seated users | |
| Scratch-resistant work surface | Melamine finish resists scuffs from office equipment, writing, and daily use | |
| Modesty panel coverage | Full-height dark side panel blocks view of users' legs from adjacent walkways | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Provides semi-private separated work zones for two adjacent employees without full cubicle walls | |
|---|---|---|
| Small business workspaces | Combines work surface and storage in one footprint to save space in small offices | |
| Start-up and co-working spaces | Neutral light wood and dark metal finish fits modern flexible office environments | |
| Shared administrative work areas | Dual zones support two admin staff with close access to shared locked file storage | |
| Home office dual-user setups | Compact footprint fits in large home offices for two people working from home |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to overall desk structural performance | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and strength test methods, applicable to work surface load validation | |
| EN 13722:2004 | Office furniture storage units safety and strength requirements, applicable to integrated drawer pedestal |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability, and structural performance for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer cycle and load performance validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood worktop and drawer components | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to steel frame and leg components | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood worktop and drawer components; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to steel frame and leg components; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
