Automatic mm / inch conversion · Core engineering specifications
| overall unit dimensions | 1800 x 1400 x 1100 mm | |
|---|---|---|
| work surface height | 750 mm | |
| main work surface depth | 700 mm | |
| knee clearance height under worktop | 670 mm | |
| desktop privacy divider height | 350 mm | |
| side storage return width | 1200 mm | |
| side storage return depth | 400 mm | |
| worktop thickness | 25 mm | |
| edge band thickness | 2 mm | |
| steel leg tube wall thickness | 1.2 mm | |
| cable grommet diameter | 60 mm | |
| upper open shelf height | 250 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| work surface static load capacity | 100 kg | |
|---|---|---|
| lockable drawer slide static load | 25 kg | |
| drawer slide cycle rating | 50000 cycles | |
| unit net weight | 45 kg | |
| recommended user capacity | 1 user per workstation section | |
| surface abrasion resistance | 2000 cycles | |
| limited warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface | 25mm melamine-faced MDF with 2mm PVC edge banding | |
|---|---|---|
| support legs | 1.2mm thick powder-coated steel angled tripod frame | |
| privacy divider | Textured terracotta fabric over MDF core, metal mounting clips | |
| storage cabinet carcass | 18mm melamine-faced particle board, off-white finish | |
| drawer hardware | Cold-rolled steel ball-bearing slides, keyed central lock | |
| adjustable feet | Nylon base with steel threaded stem, 10mm adjustment range | |
| cable grommet | ABS plastic, brushed silver finish, removable cap | |
| drawer handles | Matching brown PVC recessed pull, aligned with accent finish | |
| shelf panels | 18mm melamine-faced MDF, brown interior finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| desktop cable management | 60mm diameter grommet routes power/data cables from worktop to floor | |
|---|---|---|
| lockable file storage | Key-locked lower drawer secures documents and personal items | |
| open shelf storage | Two-tier upper open shelves provide immediate access to books and supplies | |
| workspace privacy screening | Low fabric divider blocks direct sightline between adjacent facing workstations | |
| modular configuration compatibility | Units can be connected side-by-side to create multi-seat open-plan clusters | |
| leveling adjustment | Threaded adjustable feet compensate for uneven floor surfaces under storage section | |
| knee well access | Clear open space under main work surface accommodates standard task chairs and seated leg movement | |
| under-desk cable pass-through | Circular dual-port cutout on side cabinet front routes cables out of the knee well | |
| lockable drawer internal height | 150 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open-plan corporate offices | Modular design allows clustered layout for team work zones with privacy separation | |
|---|---|---|
| small business staff work areas | Integrated storage reduces need for separate filing cabinets, saving floor space | |
| co-working shared spaces | Individual lockable storage supports flexible hot-desking user assignments | |
| startup office environments | Neutral two-tone finish matches modern casual office interior design schemes | |
| administrative workstations | Ergonomic 750mm work height and cable management support daily computer-based tasks | |
| adjacent 2-person face-to-face layouts | Center divider provides visual separation without blocking team collaboration |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to safety and strength requirements for office work tables | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Applies to dimensional requirements for office desks | |
| EN 13722:2004 | Applies to strength and durability of office storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to performance requirements for office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to performance requirements for office storage units |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3327-2016 | Applies to strength and durability requirements for office desks | |
| GB 18580-2017 | Applies to formaldehyde emission limits for wood-based panels | |
| GB/T 17657-2013 | Applies to surface finish physical property test methods |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden office furniture; 2. GB/T 3327-2016: Applies to strength and durability requirements for office desks; 3. GB 18580-2017: Applies to formaldehyde emission limits for wood-based panels; 4. GB/T 17657-2013: Applies to surface finish physical property test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
