PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall footprint	2400 x 1200 x 1100 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Work-surface distributed static load	100 kg per user position
Pedestal top drawer load	15 kg
Lower cabinet shelf load	25 kg
Recommended users	2 persons
Product net weight	96 kg
Work-surface impact and abrasion acceptance	Class HPL or melamine rated for 150,000 abrasion cycles
Drawer slide durability	50,000 open-close cycles
Leveling adjustment per foot	10 mm
Warranty period	5 years
Top Static Load Reference	150 kg uniformly distributed

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25 mm white wood-based panel with sealed impact-resistant edge banding
Privacy screens	18 mm grey fabric-wrapped or frosted panel with rounded corners
Screen clips	White molded polymer or die-cast support brackets with two fixings per panel
Exposed legs	40 x 40 mm white powder-coated square steel tubes
Pedestal structure	White steel or melamine-faced panel cabinet with grey recessed modesty panel
Hardware and feet	Steel drawer lock/latch, slide rails, hinges as applicable, and 12 mm polymer leveling feet

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Two-person facing workstation	Two users sit opposite the central divider, each receiving a 1200 x 600 mm work zone and one cable grommet
Visual privacy division	Two freestanding low screens separate opposite monitors and documents while retaining 350 mm sight-barrier height
Cable routing	Four 60 mm round grommets provide cable entry from the desktop toward the under-desk zone
Under-desk storage	Each side includes one narrow top drawer and one lower cabinet compartment for files or personal items

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Total shipping volume	0.34 CBM
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office benching	Suitable for two adjacent staff in compact open offices because the central screens reduce visual distraction while sharing structural support
Project procurement configuration	Suitable for standardized call centers, admin teams, and back-office seating where under-desk personal storage and cable ports are required

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Work-surface safety and strength	EN 527:2011 for safety, strength, and durability of office desks
Dimensions and clearance	EN 527:2002 for office desk dimensions, including seated leg clearance and work-surface height
Formaldehyde emission	EN 13986 for wood-based panels used in construction and furniture, with E1 emission classification
Fabric screen performance	EN 14465 for upholstery or panel-fabric abrasion, pilling, and colorfastness when the divider is fabric faced

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Structural safety standard	GB/T 3324for dimensional, structural, and coating requirements of wooden furniture
Formaldehyde emission	GB 18580for formaldehyde emission from wood-based furnishing materials and finished furniture
Hardware durability	GB/T 10357.5for furniture mechanical surface and component performance testing

Standardized tender description text

This product must meet the following technical requirements:
1. Structural safety standard: GB/T 3324for dimensional, structural, and coating requirements of wooden furniture;
2. Formaldehyde emission: GB 18580for formaldehyde emission from wood-based furnishing materials and finished furniture;
3. Hardware durability: GB/T 10357.5for furniture mechanical surface and component performance testing;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS2-PED-GREY-WHITE

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS2-PED-GREY-WHITE

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS2-PED-GREY-WHITEOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Person Panel-Based Office Workstation is an unbranded panel-system desk configured for two users seated opposite one another across a central low divider. Its clean white work surfaces and grey screens create a structured commercial appearance, while the paired facing layout supports shared benching without merging the two individual work zones. Each user receives a defined 1200 x 600 mm work area, a cable opening, and under-desk storage, making the layout compact and orderly for side-by-side team planning. The workstation combines white laminate surfaces with grey fabric-wrapped or frosted divider panels, rounded screen corners, and white powder-coated square steel legs. The work surface uses a white wood-based panel with sealed, impact-resistant edge banding and a finished top thickness of 50 mm. Screens are attached with white molded polymer or die-cast support brackets, with two fixings per panel. Storage is integrated into steel-and-panel pedestals featuring a white steel or melamine-faced cabinet body and a grey recessed modesty panel. Hardware includes a steel drawer lock or latch, slide rails, hinges as applicable, and 12 mm polymer leveling feet. Functionally, the divider provides visual separation between opposite monitors and paperwork while retaining a low sight-barrier height of 350 mm, helping reduce distraction in open environments without fully enclosing either seat. Four round 60 mm grommets allow desktop cables to pass toward the under-desk area, supported by an 80 mm cable opening specification and a cable tray depth of 120 mm. Each side includes a narrow top drawer and a lower cabinet compartment for files or personal items. The workspace provides 680 mm high and 900 mm wide knee clearance per main seat, with the work surface rated for a distributed static load of 100 kg per user position. The top drawer is rated for 15 kg, and the lower cabinet shelf for 25 kg. This model is well suited to open-plan offices, call centers, administration teams, back-office seating, and other standardized workplaces requiring two-person benching, privacy screening, personal storage, and cable management. It can also be considered for residential study or live-work settings where two separate work positions are needed in one coordinated station. Procurement teams should plan around a 2400 x 1200 x 1100 mm footprint, a net weight of 96 kg, and assembly time of 40 minutes per set. The supplied product references one set across two cartons, while logistics information also records packaged gross weight at 180 kg per set in four cartons and packaging volume of 1 m³ per set, so delivery and receiving details should be confirmed at order placement. Buyers specifying high-use installations should note the HPL or melamine surface acceptance for 150,000 abrasion cycles and drawer slide durability of 50,000 open-close cycles. Floor protection, level access, and available power or data positions should be checked before installation.

Two-Person Panel-Based Office Workstation with Pedestals Specifications
