Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Work surface thickness | 32 mm | |
| Knee clearance height under work surface | 650 mm | |
| Knee clearance depth under work surface | 600 mm | |
| Central privacy divider height above worktop | 350 mm | |
| Attached storage pedestal dimensions | 800 x 600 x 720 mm | |
| Drawer internal dimensions (per drawer) | 450 x 500 x 150 mm | |
| Open CPU storage bay dimensions | 300 x 550 x 480 mm | |
| Elevated divider shelf dimensions | 300 x 200 x 15 mm | |
| Leg cross-section size | 50 x 30 mm | |
| PVC edge banding thickness | 1 mm | |
| Divider panel thickness | 16 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static load capacity of work surface | 100 kg | |
|---|---|---|
| Recommended number of users | 2 | |
| Frame static load rating | 150 kg | |
| Product net weight | 85 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Structural warranty period | 5 years | |
| Available finish options | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 32mm melamine-faced particleboard with 1mm PVC edge banding | |
|---|---|---|
| Storage pedestal panels | 16mm melamine-faced particleboard with matching PVC edging | |
| Support legs | 1.2mm thick powder-coated steel with splayed angled design | |
| Central privacy divider | 16mm particleboard core with terracotta fabric face panel | |
| Drawer locks | Zinc alloy keyed cam locks, one lock per drawer | |
| Elevated shelf | 16mm melamine-faced particleboard matched to off-white finish | |
| Divider support frame | 1.0mm thick powder-coated steel bracket | |
| Leveling feet | Nylon and steel adjustable glides on pedestal base | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Lockable drawer storage | Two key-locking upper drawers for secure storage of office supplies and documents | |
|---|---|---|
| Open CPU storage bay | Open under-pedestal compartment sized to house full-size desktop computer towers | |
| Cable management access | Integrated cable routing cutout under work surface for computer and monitor power/data cords | |
| Central privacy divider | Partial height screen separating adjacent work zones to reduce visual distraction between users | |
| Elevated accessory shelf | Small raised shelf attached to divider for placing small plants, stationery, or personal items | |
| Fixed worktop height | 750mm seated work height optimized for standard office task chairs with 480 mm seat height | |
| Modular connection compatibility | Designed to connect to adjacent workstation units for larger open-plan office layouts | |
| Floor leveling adjustment | Adjustable nylon glides on pedestal base to compensate for uneven office flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff work areas | Dual work zone design for two adjacent employees in shared office floorplans | |
|---|---|---|
| Small business startup offices | Compact L-shape with integrated storage reduces need for separate filing cabinets | |
| Administrative and clerical workspaces | Integrated CPU storage and cable management suited for daily computer-based desk work | |
| Co-working space dedicated desks | Neutral light wood and white finish with privacy divider for individual dedicated work spots | |
| Home office multi-user setups | Side storage pedestal organizes supplies while separating work zones for two remote workers | |
| Call center and back-office departments | Compact footprint and privacy screen suited for dense high-density staff seating arrangements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface stability and load | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and ergonomic requirements, applicable to desk height and clearance | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction and furniture use, applicable to panel material performance | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to drawer pedestal strength and lock function |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability, and structural performance in office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard applicable to the attached lockable pedestal drawer performance | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and storage construction | |
|---|---|---|
| GB/T 3327-2017 | Performance and test methods for office desks, applicable to worktop load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture materials | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable to worktop and divider panel substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and storage construction; 2. GB/T 3327-2017: Performance and test methods for office desks, applicable to worktop load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture materials; 4. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable to worktop and divider panel substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
