Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1650 x 1400 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 260 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 45 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Recommended user count | 2 people | |
| Product net weight range | 125 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Leveling glide adjustment range | 10 mm | |
| Suggested warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop and cabinet panels | 25mm E1 grade melamine-faced chipboard (MFC) | |
|---|---|---|
| Desk support frame and legs | 1.5mm thick powder-coated steel with chrome-plated foot caps | |
| Central privacy divider | Fabric-wrapped fiberboard panel with steel accent trim | |
| Edge protection | 3mm thick high-impact PVC edge banding | |
| Drawer hardware | Cold-rolled steel ball-bearing full-extension slides | |
| Drawer panels | 18mm thick melamine-faced MDF with matching PVC edges | |
| Leveling feet | Reinforced nylon with steel threaded inserts | |
| Integrated power strip housing | Flame-retardant ABS plastic | |
| Surface finish | Stain-resistant, wear-resistant matte melamine laminate | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Dual opposing work positions | Two separate knee clearance zones for two seated staff, separated by central divider | |
|---|---|---|
| Attached storage system | Left-side cabinet with upper open shelf, lockable small utility drawer and large hanging file drawer | |
| Integrated cable management | Desktop mounted power strip with cable routing slots to under-desk cable space | |
| Floor leveling adjustment | Threaded glide feet on all leg bases to adjust for uneven carpet or hard flooring | |
| Privacy separation | 350mm tall fabric divider blocks direct line of sight between opposing users | |
| Drawer operation | Full-extension ball-bearing slides allow 100% drawer access with smooth, quiet movement | |
| Lockable storage | Keyed lock secures both drawers for confidential document storage | |
| Modular compatibility | Pre-drilled connection points allow linking to additional workstations for open office layouts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Two-person footprint fits high-density open office layouts without separate cubicle walls | |
|---|---|---|
| Small team and start-up offices | All-in-one storage and work surface reduces need for separate filing cabinets | |
| Government and educational administration offices | Durable commercial construction meets daily high-traffic office use requirements | |
| Shared work and co-working spaces | Neutral color scheme with accent divider works in flexible shared work environments | |
| Corporate department work zones | Modular design allows linking multiple units to create larger team work clusters | |
| Recommended configuration | Pair with two ergonomic mesh task chairs, monitor arms and under-desk cable trays for full setup |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desktop load and stability | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety requirements, applicable to desk height and clearance | |
| EN 13986:2004 | Wood-based panels for construction and furniture, formaldehyde emission performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to structural durability and load testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer slide and cabinet durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk construction quality | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks, applicable to structural load and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use | |
| GB/T 4897.3-2003 | Requirements for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk construction quality; 2. GB/T 3327-2017: Performance requirements for office desks, applicable to structural load and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use; 4. GB/T 4897.3-2003: Requirements for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
