Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 1830 x 1830 x 1650 mm | |
|---|---|---|
| Desktop working height | 762 mm | |
| Desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Cable grommet opening diameter | 60 mm | |
| Desktop privacy divider height above surface | 300 mm | |
| Attached rear hutch height above desktop | 914 mm | |
| Under-desk knee clearance height | 673 mm | |
| Return side storage cabinet depth | 450 mm | |
| Support leg diameter | 45 mm | |
| Drawer internal usable dimensions | 305 x 483 x 152 mm | |
| Hutch open shelf internal height | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Unit total net weight | 240 kg | |
| Melamine surface abrasion resistance | 20000 rubs | |
| Steel frame salt spray corrosion resistance | 48 hours | |
| Recommended user count | 1 person | |
| Drawer slide cycle durability | 50000 cycles | |
| Leveling foot adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | E0-grade high-density fiberboard (720 kg/m³) | |
|---|---|---|
| Desktop surface finish | Thermally fused melamine laminate, scratch and stain resistant | |
| Edge protection | 2mm thick hot-melt PVC edge banding | |
| Support legs | 1.2mm thick cold-rolled steel, dark gray powder coated | |
| Privacy divider panel | Rigid light beige composite panel with metal mounting clips | |
| Storage cabinet panels | Melamine-faced engineered wood, dark gray/light gray two-tone finish | |
| Drawer hardware | Steel ball-bearing full-extension slides with keyed locks | |
| Cable management grommet | Black ABS plastic flip-top cable port | |
| Leveling feet | Reinforced nylon adjustable glides | |
| Hutch shelf panels | 18mm thick melamine-faced engineered wood | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Privacy divider function | Fixed desktop-mounted screen blocks direct line of sight between adjacent workstations | |
|---|---|---|
| Cable management system | Desktop grommet routes power and data cables from work surface to under-desk area | |
| Drawer locking mechanism | Keyed lock secures two front-facing drawers for confidential document storage | |
| Overhead hutch storage | Divided open shelves provide accessible storage for binders, supplies and desk accessories | |
| Under-desk open storage | Two divided open compartments under return surface accommodate CPU towers and large items | |
| Floor leveling function | Adjustable nylon feet on cabinet base and legs compensate for uneven office flooring | |
| Modular connectivity | Pre-drilled frame allows connection to adjacent matching workstations for cubicle clusters | |
| Edge protection function | PVC edge banding prevents panel chipping and moisture ingress at high-impact desk edges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Provides individual work zones with privacy dividers for staff in shared floorplans | |
|---|---|---|
| Corporate administrative departments | Integrated storage reduces desk clutter for daily paperwork and computer work | |
| Call center and shared workspace environments | Standard desk height and cable management support monitor, keyboard and phone setups | |
| Government and institutional offices | Durable commercial-grade construction meets frequent use requirements for public sector facilities | |
| Small business office fit-outs | Self-contained L-shaped layout requires no additional storage furniture for single users | |
| Temporary project workspace setups | Knock-down design allows reconfiguration or relocation between office spaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk stability and load testing | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability requirements, applicable to drawers and hutch | |
| EN 71-3:2019 | Migration of certain elements for surface materials, applicable to laminate and paint finishes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products standard for safety, durability and structural performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer slide performance and lock durability in office applications |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel office desk construction | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration materials, E0 grade ≤0.05mg/m³ for panel components | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to structural panel core requirements | |
| GB 20286-2006 | Flame retardant requirements for public furniture, applicable to screen panel material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel office desk construction; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration materials, E0 grade ≤0.05mg/m³ for panel components; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to structural panel core requirements; 4. GB 20286-2006: Flame retardant requirements for public furniture, applicable to screen panel material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
