| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1830 x 1400 x 1100 mm | |
|---|---|---|
| work surface height | 762 mm | |
| desktop thickness | 38 mm | |
| edge banding thickness | 2 mm | |
| privacy screen dimensions | 1400 x 305 mm | |
| seated knee clearance height | 673 mm | |
| integrated return storage unit width | 1200 mm | |
| storage unit depth | 600 mm | |
| upper open shelf compartment height | 300 mm | |
| lower double-door cabinet internal height | 450 mm | |
| cantilever steel frame section size | 60 x 30 mm | |
| cable grommet diameter | 80 mm | |
| leveling foot adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| desktop static load capacity | 91 kg | |
|---|---|---|
| unit net weight | 154 kg | |
| recommended user capacity | 1 person | |
| laminate surface abrasion resistance | 2000 cycles | |
| drawer slide cycle rating | 50000 cycles | |
| cabinet door hinge cycle rating | 80000 cycles | |
| structural warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface substrate | E1 grade MFC particleboard | |
|---|---|---|
| work surface finish | Matte white heat-resistant laminate | |
| edge banding | 2mm thick impact-resistant PVC | |
| support frame | 1.5mm thick powder-coated steel | |
| privacy divider facing | Woven polyester tackable fabric | |
| privacy divider core | 12mm thick medium-density fiberboard | |
| storage cabinet panels | 18mm thick melamine-faced engineered wood | |
| hardware components | Zinc-plated steel drawer slides, hinges and lock | |
| leveling feet | Reinforced nylon with steel threaded stem | |
| cable management components | ABS plastic grommets and under-desk cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| drawer lock mechanism | Single keyed lock secures upper drawer, limits access to stored valuables | |
|---|---|---|
| leveling foot adjustment | Threaded feet at all support points adjust to compensate for uneven floor surfaces | |
| cable management system | Desktop grommets route power and data cables to under-desk tray, reducing surface clutter | |
| privacy screen function | Desk-mounted fabric divider reduces visual distraction between adjacent workstations | |
| upper open shelf storage | Two divided open shelves above work surface hold frequently used books and reference materials | |
| lower cabinet storage | Double-door enclosed cabinet conceals bulkier office supplies and personal items | |
| cantilever leg design | Open O-frame leg provides unobstructed knee and leg room for seated users without a front modesty panel | |
| drawer slide operation | Full-extension ball-bearing slides allow complete access to drawer contents without binding | |
| lockable drawer internal height | 150 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open-plan office staff workstations | Low divider provides visual privacy while maintaining open collaboration space | |
|---|---|---|
| small business administrative work areas | Integrated storage eliminates need for separate filing cabinets to save floor space | |
| home office professional workspaces | Neutral white finish and ample storage support daily telecommuting and document work | |
| call center agent work positions | Cable management and lockable storage support secure, organized daily headset and computer use | |
| co-working space dedicated desks | Durable laminate construction and secure storage support frequent rotating user access | |
| adjacent multi-seat cluster expansion | Standard width allows connection to matching units for 2/4/6-person workstation rows |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural stability verification | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units performance requirements, applicable to cabinet and drawer durability | |
| EN 13986:2004+A1:2015 | Wood-based panels formaldehyde emission classification, applicable to substrate compliance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desks products standard, applicable to desk load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to drawer and cabinet performance verification | |
| ANSI/BIFMA X7.1-2022 | Formaldehyde and TVOC emission standard for office furniture, applicable to indoor air quality |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and storage panel construction | |
|---|---|---|
| GB/T 3327-2016 | Technical requirements for office desks, applicable to work surface strength and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to engineered wood substrate verification | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desktop load and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and storage panel construction; 2. GB/T 3327-2016: Technical requirements for office desks, applicable to work surface strength and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to engineered wood substrate verification; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desktop load and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
