Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3200 x 1200 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Seated knee clearance height | 725 mm | |
| Long-side per-user seating width | 800 mm | |
| End-side per-user seating width | 1200 mm | |
| Central support pedestal dimensions | 600 x 300 x 725 mm | |
| A-frame leg splay angle | 22 degrees from vertical | |
| Brown accent bracket size | 120 x 80 mm | |
| Adjustable foot pad diameter | 50 mm | |
| PVC edge banding thickness | 2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total static load capacity | 1200 kg | |
|---|---|---|
| Laminate surface abrasion resistance | 2000 cycles | |
| Recommended seated user capacity | 8 people | |
| Product net weight | 120 kg | |
| Adjustable foot level adjustment range | 20 mm | |
| Manufacturer limited warranty | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | E1 grade high-density particleboard | |
|---|---|---|
| Tabletop surface finish | Matte white thermally fused laminate | |
| Edge treatment | 2mm thick matching white PVC edge banding | |
| A-frame end legs | 2mm thick powder-coated off-white steel | |
| Central support pedestal | 18mm thick E1 grade engineered wood with white laminate | |
| Leg-top junction brackets | 3mm thick powder-coated brown steel | |
| Foot pads | 50mm diameter non-slip TPE rubber pads | |
| Assembly hardware | Zinc-plated steel bolts and cam locks | |
| Surface coating performance | Scratch and stain resistant laminate | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Level adjustment | TPE foot pads adjust 20mm vertically | |
|---|---|---|
| Seating access | Unobstructed knee clearance along both long sides | |
| Modular configuration | Connectable to matching table segments for extended length | |
| Cable management compatibility | Drillable grommet holes available for AV and power cabling | |
| Edge safety | Smooth rounded PVC edges eliminate sharp corners | |
| Floor protection | Rubber foot pads prevent scratches on hard office flooring | |
| Surface maintenance | Non-porous laminate surface wipes clean with standard office cleaners | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Primary application space | Mid-sized corporate conference rooms | |
|---|---|---|
| Secondary application space | Open office collaboration zones | |
| Compatible seating recommendation | Sled-base or four-leg meeting chairs with 450mm seat height | |
| Compatible AV equipment | Wall-mounted whiteboards, ceiling projectors and tabletop conferencing devices | |
| Target user segment | Small to medium businesses, co-working spaces and corporate branch offices | |
| Recommended floor types | Polished concrete, vinyl tile and low-pile carpet office flooring | |
| Available finish options | Matte white, light grey and black tabletop finishes |
EU Market Access Requirements* EN Standards
| Office furniture safety standard | EN 527:2016 | |
|---|---|---|
| Formaldehyde emission standard | EN 13986:2004+A1:2015 | |
| Surface reaction to fire standard | EN 13501:2018 |
US and Canada office-furniture standards
| Office table performance standard | ANSI/BIFMA X2021 |
|---|
Standards applicable to China-market projects
| Tabletop substrate emission standard | GB/T 18580 | |
|---|---|---|
| Office table structural stability standard | GB/T 3326 | |
| Laminate surface durability standard | GB/T 17657 |
This product must meet the following technical requirements: 1. Tabletop substrate emission standard: GB/T 18580; 2. Office table structural stability standard: GB/T 3326; 3. Laminate surface durability standard: GB/T 17657; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
