| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 2400 x 600 x 750 mm | |
|---|---|---|
| per-user work surface size | 1200 x 600 mm | |
| desktop privacy divider height | 300 mm above desktop | |
| under-desk knee clearance height | 670 mm | |
| knee opening width per user | 600 mm | |
| desktop thickness | 25 mm | |
| storage pedestal width | 400 mm | |
| pedestal drawer height | 120 mm | |
| lower cabinet door height | 530 mm | |
| CPU storage bay internal dimensions | 250 x 500 x 480 mm | |
| side modesty panel height | 725 mm | |
| edge band thickness | 1 mm | |
| support leg wall thickness | 1.2 mm | |
| leveling foot height adjustment | 10 mm | |
| modesty panel thickness between users | 16 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static load capacity | 113 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 open/close cycles | |
| desktop laminate abrasion resistance | 2000 cycles | |
| unit gross packed weight | 145 kg | |
| maximum user weight support | 150 kg per seat | |
| commercial hardware warranty | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| desktop surface | 25 mm E1-grade engineered wood with thermally fused light oak laminate | |
|---|---|---|
| desktop privacy dividers | Fabric-wrapped fiberboard panels with matte black mounting clips | |
| modesty panels and storage bodies | 16 mm black laminated particle board | |
| edge banding | 1 mm thick PVC edging applied to all exposed panel edges | |
| support frame and leveling feet | 1.2 mm thick powder-coated steel tubing with nylon adjustable feet | |
| storage hardware | Steel three-section ball-bearing drawer slides, integrated combination drawer locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| workspace separation | Low fabric dividers create independent visual zones for two side-by-side users | |
|---|---|---|
| secure storage | Each integrated pedestal includes a lockable upper drawer and lower cabinet | |
| computer storage | Recessed open bays under each work position hold two mid-tower CPUs | |
| leveling adjustment | Small adjustable feet at base corners compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| open plan office staff areas | Provides two dedicated independent workstations with visual privacy for team seating | |
|---|---|---|
| small business back office spaces | Integrated storage and CPU bays reduce need for separate furniture units |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional, safety and strength requirements for workstations | |
| EN 13722:2004 | Furniture storage units strength and durability requirements for pedestal cabinets |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated drawer pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel workstations | |
|---|---|---|
| GB/T 4897.3-2003 | Particle board for furniture use, applicable to structural desk panels | |
| GB 18584-2001 | Limits of formaldehyde emission for wooden furniture, required for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel workstations; 2. GB/T 4897.3-2003: Particle board for furniture use, applicable to structural desk panels; 3. GB 18584-2001: Limits of formaldehyde emission for wooden furniture, required for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
