PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed static work-surface load	120 kg total
Per-workzone monitor and equipment load	30 kg
Net product weight	95 kg
Recommended occupancy	4 users
Modesty panel lateral stability load	30 kg horizontal force
Divider attachment pull-off resistance	50 kg per bracket
Surface uniform distributed load	300 kg/m2
Adjustable foot leveling range	10 mm
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	Walnut-grain melamine-faced wood-composite board, 25 mm thick, with impact-resistant sealed edge
Edge banding	Dark PVC or ABS edge banding around the worktop, 2 mm thick
Support frame	Charcoal powder-coated square steel legs and perimeter rails, 50 x 50 mm section
Central divider	Blue woven fabric upholstery over a composite or fiberboard core, 32 mm thick
Modesty panels	Dark charcoal rigid panel with a wood-grain end panel, framed as a fixed under-desk enclosure
Screen brackets	Satin silver or gray metal divider support brackets, two visible brackets clamping to the work surface

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating arrangement	Four users work face-to-face in two paired stations separated by the central upholstered divider
Cable routing	Four rectangular cable ports direct wires from the work surface into the under-desk cable zone
Visual privacy	The 350 mm-high central divider reduces direct sightlines while retaining seated communication across the bench
Fixed installation	The desk uses a bolted fixed-leg frame and attached modesty panels rather than a height-adjustable or folding mechanism

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton count	4 flat-packed cartons
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office neighborhoods	Suits four-person project teams where face-to-face discussion is needed but low-level visual separation is required
Task-based workstation areas	Supports monitors, laptops, documents, and task chairs through 1200 mm-wide per-user work zones and under-desk clearance

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011+A1:2019	Office desk safety, strength, and durability requirements, applicable to the fixed commercial workstation structure
EN 527-2:2011+A1:2019	Office desk dimensional requirements, applicable to 750 mm work height and seated leg-clearance verification
EN 16139:2013+A1:2020	Strength, durability, and stability requirements for non-domestic seating-area furniture, applicable where bench screens are loaded during use

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Office desk and table products standard, applicable to static load, leg strength, stability, and durability acceptance
BIFMA E3-2022 Furniture Sustainability Standard	Optional multi-attribute sustainability assessment for panel materials, coatings, packaging, and supply-chain disclosure
ANSI/BIFMA G1-2013	Ergonomics guideline for office furniture, applicable to seated work height, knee space, and task-chair compatibility

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2024	General technical requirements for wooden furniture, applicable to the wood-composite worktop and panel finish inspection
GB/T 3325-2017	Metal furniture general technical requirements, applicable to steel leg strength, coating, and welded or bolted joints
GB 18580-2017	Formaldehyde emission control for wood-based panels, applicable to desk boards, divider core, and modesty panel substrates
GB/T 10357.1-2013	Table mechanical stability test method, applicable to desk stability acceptance on level flooring
GB/T 10357.5-2011	Table strength and load test methods, applicable to static top loading and leg-connection verification

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2024: General technical requirements for wooden furniture, applicable to the wood-composite worktop and panel finish inspection;
2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel leg strength, coating, and welded or bolted joints;
3. GB 18580-2017: Formaldehyde emission control for wood-based panels, applicable to desk boards, divider core, and modesty panel substrates;
4. GB/T 10357.1-2013: Table mechanical stability test method, applicable to desk stability acceptance on level flooring;
5. GB/T 10357.5-2011: Table strength and load test methods, applicable to static top loading and leg-connection verification;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-BENCH-4P-WAL-BLUE

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-BENCH-4P-WAL-BLUE

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-BENCH-4P-WAL-BLUEOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Four-Person Bench Workstation with Central Divider and Modesty Panels is an unbranded office workstation designed for team-based bench seating. Model WS-BENCH-4P-WAL-BLUE, it presents four workzones in a face-to-face layout, with two paired stations on each side of a central upholstered divider. The walnut-look work surfaces establish a warm office appearance, while the charcoal frame, dark modesty panels, and blue woven divider give the bench a structured, contemporary visual contrast. The divider is 350 mm high and supported by visible satin silver or gray metal brackets, reducing direct sightlines without fully isolating users, so seated communication across the bench remains practical. Dark PVC or ABS edge banding complements the worktop and provides a crisp border around each surface. Its construction combines walnut-grain melamine-faced wood-composite board, a charcoal powder-coated square steel frame, fixed support legs, perimeter rails, and attached under-desk modesty panels. The work surface uses 25 mm board with an impact-resistant sealed edge and has a finished top thickness of 50 mm. The main legs and rails use a 50 x 50 mm steel section, while the main support leg section is specified at 80 mm with a 2 mm metal wall. The 32 mm divider has blue woven fabric upholstery over a composite or fiberboard core. Dark charcoal rigid modesty panels, with a wood-grain end panel, form a fixed enclosure beneath the desk. Functionally, the workstation is built for four users and supports monitors, laptops, documents, and task chairs in 1200 mm-wide per-user workzones. Each main seat provides 680 mm of knee clearance height and 900 mm of width. Four rectangular cable ports direct cabling from the work surface into an under-desk cable zone served by an 80 mm cable opening and a cable tray with 120 mm depth. The fixed bolted frame is intended for stable installation rather than height adjustment or folding storage. Rated capacities include a 120 kg distributed static work-surface load, a 30 kg equipment load per workzone, and a 300 kg/m2 uniform distributed surface load. The modesty panels are rated for 30 kg of horizontal lateral force, and divider brackets provide 50 kg pull-off resistance per bracket. At 95 kg net weight, the bench suits open-plan office neighborhoods, four-person project teams, and task-based work areas where discussion and moderate visual separation are both important. It can also serve a residential study or co-working setting where a coordinated four-seat layout is required. Procurement teams should plan for fixed placement, assembly, cable management access, task-chair compatibility, and delivery handling. The product is supplied flat packed in four cartons, with a packaged gross weight of 180 kg per set and packaging volume of 1 m³ per set; the stated reference assembly time is 40 minutes per set. Buyers should verify the latest package configuration, site access, floor protection, and installation responsibility before ordering.

Four-Person Bench Workstation with Central Divider and Modesty Panels Specifications
